Cards and Adapters
Dell™ OptiPlex™ GX260 Service Manual
Small Form-Factor Computer
Small Desktop Computer
Small Mini-Tower Computer
Your computer provides slots for the following cards:
In the small form-factor computer, one low-profile, 32-bit, 33-MHz PCI card or serial port adapter; one DVI adapter
card or one 32-bit, low-profile AGP 4x card operating at 1.5 V.
In the small desktop computer, two 32-bit, 33-MHz PCI cards or one PCI card and one serial port adapter; one DVI
adapter card or one 32-bit, low-profile AGP 4x card operating at 1.5 V.
In the small mini-tower computer, four 32-bit, 33-MHz PCI cards or three PCI cards and one serial port adapter; one
DVI adapter card or one 32-bit, AGP 4x card operating at 1.5 V.
NOTE: Before disconnecting a device from the computer or removing a component from the system board, verify that
the auxiliary power light on the system board is off. For the location of this light, see
Small Form-Factor Computer

PCI Cards

Serial Port Adapters
AGP and DVI Adapter Cards
PCI Cards

Installing a PCI Card

CAUTION: Before you perform this procedure, see
1. If you are replacing a card, remove the current driver for the card from the operating system.
2. Raise the retention arm.
Raising the Retention Arm
"Precautionary Measures."
"System Board."
