Pinguino is equipped with an adjustable win-
dow bracket ( 18) . If you have a sliding win-
dow, place the bracket on the window sill,
extend the bracket fully within the window
frame and lower the window onto the brack-
et. Insert the nozzle of the exhaust hose into
the slot, then connect the hose to the air con-
ditioner (Fig.4).
Thanks to the wing nut, it's possible to use the
window bracket also for sliding windows. Position
the hole of the bracket to allow a correct instal-
lation of the exhaust hose (see the following
instructions).
4
8
Pagina 8
S e t t i n g u p
If you have a sliding door, use the additional
set provided in order to extend the accessory
to the desired length; joining the two parts
(fig. 5), adjust the total length according to
your needs then, fit the bracket with the rele-
vant nuts, close the door and connect the
hose (fig. 6).
5
6
