RHB SERIES GAS LOG BURNER
INSTALLATION AND OPERATING INSTRUCTIONS
WARNING:
maintenance can cause injury or property damage. Refer to this manual. For
assistance or additional information, consult a qualified installer, service agency or
the gas supplier.
IMPORTANT:
READ INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION OF LOG SET.
NOTE: DAMPER MUST BE OPEN ACCORDING TO CHART ON PAGE 3 OF THESE
INSTRUCTIONS OR FULLY OPEN WHEN LOG SET IS OPERATING.
This burner unit must be installed only in a fully-vented, solid-fuel burning fireplace with a working flue and constructed of
noncombustible material. The damper and chimney must be free of any obstructions. This log set is designed to burn with a
smoky, yellow flame and must be vented for this reason. The fireplace chimney must have a permanent vent opening to the
atmosphere of not less than the minimum square inches stated in Table 1 and Table 2 on page 3 of these instructions. If it is
smaller, do not use this log set.
IMPORTANT:
Ensure that the chimney draft is adequate by holding a lit match or candle at the top edge of the fireplace
opening. This will indicate if air movement is toward the fireplace. If draft is inadequate, do not operate logs until draft is
adequate. If you smell fumes from the burner in the room when the damper is fully open, it indicates that the fireplace draft
is insufficient. If the draft is insufficient, have the chimney inspected by a qualified chimney sweep.
LOGS UNTIL THE FIREPLACE DRAFT IS CORRECTED.
decorative appliance is installed.
14-2000
Champion and Radiance Log Sets

FOR YOUR SAFETY

Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
Improper installation, adjustment, alteration, service or
for
Do not burn solid fuels in a fireplace where a
DO NOT OPERATE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gas Burner and is the answer not in the manual?

Questions and answers

Related Manuals for Heatmaster Gas Burner

Summary of Contents for Heatmaster Gas Burner

  • Page 1: For Your Safety

    This will indicate if air movement is toward the fireplace. If draft is inadequate, do not operate logs until draft is adequate. If you smell fumes from the burner in the room when the damper is fully open, it indicates that the fireplace draft is insufficient.

  • Page 2: General Information

    Periodically you may want to remove the soot build-up on the logs by lightly brushing the logs with a soft brush. Also, occasionally, visually inspect your burner pan and pilot for proper operation (Fig. 1 and Fig. 2 below). Fig. 1...
  • Page 3 Minimum Permanent Free Opening, Square Inches for Masonry Built Fireplaces Chimney Height (Feet) Minimum Permanent Free Opening, Square Inches for Factory Built Fireplaces Chimney Height (Feet) 18” Log Set 24” Log Set Minimum Opening (Square Inches) 49.2 45.5 41.7 37.7 34.3 31.2 Table 1...

  • Page 4: General Installation

    This log set must be installed by a qualified person and instructions must be followed exactly to ensure safe operation. Your log set is packaged in three (3) boxes. The complete burner assembly is packaged in one box and the logs are packaged in separate boxes.

  • Page 5: Log Placement

    LOG PLACEMENT 1. Remove the fiber log and place it in the middle of the burner unit, with the charred face of the log facing the room. Line up the two holes in the bottom of this log with the two 3/8” pegs and gently slide the log over the pegs until it rests on the grate.
  • Page 6 RAD-18 CHML-18 LOG PARTS LIST FOR CHML-18 & 24 and RAD-18 & 24 LETTER PART NO. Log # 381 Front Log - RAD-18 Log # 363 Front Log - RAD-24 Log # 382 Front Log - CHML-18 Log # 364 Front Log - CHML-24 Glow Middle Log - RAD-18 Log # CF LOG 106...

  • Page 7: For Your Safety Read Before Lighting

    5. Turn control handle counterclockwise 6. Place a lit match at the pilot burner and simultaneously push in the control handle. This should ignite the pilot. 7. Once the pilot lights continue to depress the control handle for one (1) minute.

  • Page 8: Lighting Instructions Manual Valve

    “B” in the safety information above on this label. If you don’t smell gas, go to the next step. 4. Place a lit match on the pan burner fill material close to the back center of the bottom pan. 5. Slowly open the gas valve by rotating the control handle counterclockwise 6.
  • Page 9 4. Locate pilot (Fig. 8) - located in the center behind the middle stainless steel burner underneath the middle log. 5. Turn (MAIN) control handle counterclockwise 6. Place a lit match at the pilot burner, and simultaneously push in on the(MAIN) control knob. This should ignite the pilot.

  • Page 10: Remote Control

    6. Plug the larger female terminal from the receiver on the larger male terminal of the valve. 7. It is best to place the receiver in the fireplace as far away from the burner unit as possible to protect it from heat. Make sure the receiver eye is facing the room so it can receive the signal from the transmitter.

  • Page 11: Parts List

    14-1019 Rod Handle 5.5” 08-905 Gas Control Valve (Manual) Parts may be ordered from your local retailer or from: HEATMASTER, INC. Route 2, Box 48 Angier, NC 27501 (919) 639-4568 When ordering, please include complete part number, part name and gas type.
