- Page 1 User guide Conference unit Konftel 60W English Conference phones for every situation...
- Page 2 The Bluetooth ® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such trademarks by Konftel is under license. Other trademarks and trade names belong to their respective owners. This product is equipped with OmniSound ®...
-
Page 3: Table Of Contents
Contents Using Bluetooth Connection ......... 2 Preparing the phone ......3 Adding to devices ........ 3 Resetting ..........3 Ring signal ......... 3 Call ............ 4 Adjusting loudspeaker volume ....4 Mute function ........4 Tuning ..........5 Disconnecting the Bluetooth link ..5 Deactivating Bluetooth ...... -
Page 4: Using Bluetooth
Some phones do not support all functions. For further information, please refer to the phone user guide. The Konftel 60W is designed to support the headset and handsfree profile for the Bluetooth standard 1.1. If the GSM network has reduced functionality, this may give poor coverage and... -
Page 5: Preparing The Phone
Using Bluetooth Preparing the phone To be able to use the Konftel 60W with your phone, you need to add it to the list of devices (also called ‘pairing’). The Konftel 60W can store up to 8 phones. To achieve optimal performance, the distance between the Konftel 60W and the phone should not exceed 5 meters. -
Page 6: Call
Konftel 60W rings, and then press the On/Off button. Making a call Make a call with your telephone as usual and transfer the call from your phone to the Konftel 60W. Please refer to your phone User Guide for instructions. Transferring a call During a call, press the On/off-button for 2 seconds to transfer the call back to your phone. -
Page 7: Mute Function
Press again to switch on the microphone. Automatic tuning The sound is adjusted automatically to eliminate echoes when the Konftel 60W is switched on. It also senses changes in your room and continual- ly adapts itself during the call. Manual tuning The Konftel 60W can be manually tuned at any time to eliminate echoes. -
Page 8: Special Functions: Voice Command Calls
Using Bluetooth – Special functions These functions only work if your telephone sup- ports them. Making a call using voice command Hold the + button for up to 2 seconds until you hear a short beep. For more information on voice 2 sec. -
Page 9: Rejecting A Call
You can transfer an active call from your phone 2 sec. to the Konftel 60W by pressing the On/Off but- ton for 2 seconds. Transfer the active call back to the phone by pressing the On/Off button for 2 seconds. -
Page 10: Using A System Phone
Using a System phone Only mains transformers of types Helms-Man DEN4824129, DPX481821 (USA) or DBN4824129 (UK) may be connected. Microphone Indicator lights Loudspeakers Mute button On/off button + button - button Tuning button IMPORTANT Adjust the microphone volume when installing the unit. See next page. -
Page 11: Call
Making a call Lift the handset, make a call and put the hand- set to one side. Switch to loudspeaker by turning on your Konftel 60W. Ending a call To end the call, replace the handset and press the On/Off button. -
Page 12: Connection
DPX481821 (USA) or DBN4824129 (UK) may be connected. Connection to PC The Konftel 60W is connected to a sound card on a PC or Macintosh as illustrated. Note: To obtain full duplex speech, you must have an appropriate sound card. -
Page 13: Adjusting Loudspeaker Volume
Loudspeaker volume Select Volume and adjust the loudspeaker volume for Line out (or PC speaker). The volume can be adjusted via the Konftel 60W when necessary. Microphone volume Select Volume by the microphone volume. -
Page 14: Accessory: Usb Adapter
The USB adapter connects to the USB port on your computer and functions as an extra sound card. Connection cable power, 6 m Power supply Underside of the Konftel 60W 230 V / 120 V (USA) power socket USB port of your computer USB adapter with cable. Item no 900102058... -
Page 15: Accessory: Bluetooth Adapter
Enter the tab Audio and make sure that the USB headset is the default device. Loudspeaker volume Select Volume and adjust the loudspeaker volume. The volume can be adjusted via the Konftel 60W when necessary. Microphone volume Select Volume by the Microphone volume. Adjust the microphone volume for Mic in. -
Page 16: Accessory: Mobile Cables
Accessory: Mobile cables Connection The Konftel 60W is connected to a GSM or wireless DECT telephone using an accessory cable, as illustrated. Cables are available for most models on the market. Refer to www.konftel.com Accessories. Power supply Underside of the... - Page 17 DPX481821 (USA) or DBN4824129 (UK) may be connected. Placement You can place your Konftel 60W up to 10 metres from the telephone or computer. To achieve optimal performance, the distance between the Konftel 60W and the phone should not exceed 5 meters.
-
Page 18: Accessory: Extra Microphones
Once they are connected, the built-in microphone of the Konftel 60W is disconnected. A short beep indicates that the connection was suc- cessful and that the software in the Konftel 60W has been upgraded. The expansion microphones are supplied with two sets of cable, 1.5 m and 2.5 m. -
Page 19: Additional Accessories
Accessories Art no. Designation 900102038 Extension cable, tele, 10 m. 9164032 Extension cable, power supply, 10 m. 9146030 Wall mounting bracket. GSM/DECT connection cables, see www.konftel.com, Accessories Konftel 60W. 900102070 Soft case. 900102058 USB adaptor. 900102066 Expansion microphones (1 pair). -
Page 20: Troubleshooting
Some problems that may arise when using the Konftel 60W are described below. Connection and pairing 1. The Konftel 60W does not appear in the display when you try to add a new device to the phone. Make sure you have followed the instructions on page 3. - Page 21 Instead of a handset, you can connect a headset to the switchbox. You may now switch between a call via the headset or the Konftel 60W via the On/Off button. Note that the headset must be adapted to suit your telephone system.
-
Page 22: Technical Data
Can be connected to virtually all system phones on the market. Cabling PC Y cable: 1 x Modular 6/4, 2 x Tele 3.5 mm. The plug for connecting the Konftel 60W to a PC may only be connected to SELV voltage (as per SS-EN60950). -
Page 23: Warranty
Responsibility for loss or damage does not transfer to Konftel until the returned item has been received by Konftel. The repaired or replaced item will be shipped to the Customer, at Konftel’s expense, not later than twelve days (12) days after Konftel has received the defective product, and Konftel will retain risk of loss or damage until the item has been delivered to the Customer. -
Page 24: Service
+46-90706489 Monday to Friday 8.00 to 17.00 (GMT:-1) email: info@konftel.com If you purchased your product from an authorised Konftel distributor, please contact that distributor for information about service agreements that apply for your product. LIMITATION OF LIABILITY. TO THE FULL EXTENT ALLOWED BY LAW, KONFTEL... -
Page 25: Fcc Statement
REN is separately shown on the label.] NOTICE: If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this Konftel 50 does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer. -
Page 26: Fcc Information And Csa Information
FCC Information and CSA Information The FCC Wants You To Know In the unlikely event that your phone causes problems on the phone line, the phone company can temporarily discontinue your service. If this happens, the phone company attempts to notify you in advance. If advance notice is not practical, the phone company notifies you as soon as possible and advises you of your right to file a complaint with the FCC. - Page 27 Konftel is a leading company within loudspeaker communication and audio technology. We develop and sell products and technology for telephone meetings based on cutting-edge expertise within acoustics and digital signal processing. Characteristic of our products is that all conference ®...
