Zoom 3G+ Modem/Router User Manual page 66

Server IP
This is the IP Address of the computer or gaming device that you want to
allow access to. If you do not know the IP address you can look it up by
selecting Basic Settings > DHCP Server, then clicking on Client List. To
make this virtual server permanent, then you should set up a fixed mapping
to your computer or gaming device on the DHCP Server page. Doing this
ensures that your computer will keep the same IP address
Service Ports
This is the port number you want to allow access to your computer on. To
enter multiple ports use the dash format; for example, 2004-2009.
Private Ports
This Modem/Router receives incoming packets on the specified Service
Port(s). You can change the destination port to a different port number. The
packet is then passed to the LAN using the Private Port destination port
number..
Protocol
Select UDP, TCP, or Both depending on what type of protocol your game or
application uses.
Enable
Click to enable the Virtual Server
Use Rule#
You can enable your virtual server for certain periods of time by assigning it
a Rule #. You must first set up the appropriate Scheduling Rule. See
Schedule Rule and Schedule Rule Setting Pages
information.
For example, if you have an FTP server (port 21) at 192.168.2.5, a Web server (port
80) at 192.168.2.6, and a game at 192.168.2.7, then you need, at minimum, to specify
the following mapping.
ID Service Port
1 21
2 80
3 5000
66
Server IP
192.168.2.5
192.168.2.6
192.168.2.7
3G+ Modem/Router with Wireless-N and Phone Port User Manual
on page 82 for more
Enable
Yes
Yes
Yes
The
