- Page 1 User Manual...
-
Page 2: Table Of Contents
5. Technical Information ..............10 Product Maintenance .................. 10 General Troubleshooting ................11 Contact Procedure ..................12 CHAUVET® Contact Information ..............12 Returning Products to CHAUVET® .............. 12 6. Technical Specifications ..............13 Page 2 of 13 Minisphere™ 3 User Manual (Rev. 4) -
Page 3: Before You Begin
If the container or the contents appear damaged from shipping, notify the carrier immediately, not CHAUVET®, upon receipt. Failure to do so in a timely manner may invalidate your claim with the carrier. In addition, keep the container and all the packing material for inspection. -
Page 4: Product At A Glance
Product at a Use on Dimmer Auto Programs Glance Outdoor Use Auto-ranging Power Supply Sound Activated Replaceable Fuse User Serviceable Master/Slave Duty Cycle Safety Notes Please read the following Safety Notes carefully before working with the product. The Notes include important safety information about installation, usage, and maintenance. -
Page 5: Introduction
2. I NTRODUCTION Product Overview DMX In DMX Out Power In & Fuse Holder Minisphere™ 3 User Manual (Rev. 4) Page 5 of 13... -
Page 6: Product Dimensions
Product Dimensions Page 6 of 13 Minisphere™ 3 User Manual (Rev. 4) -
Page 7: Setup
3. S ETUP AC Power The Minisphere™ 3 has an auto-ranging power supply that works with an input voltage range of 100~240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 8: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in Safety Notes section in this manual). Orientation The Minisphere™ 3 may be mounted in any position; however, make sure adequate ventilation is provided around the product. • Rigging Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes. -
Page 9: Operation
4. O PERATION Configuration Set the product in DMX mode to control with a DMX controller. Connect the product to a suitable power outlet. (DMX) Turn the product on. Connect a DMX cable from the DMX output of the DMX controller to the DMX input socket on the product. -
Page 10: Dmx Channel Assignments And Values
Set the master product to operate in either Automatic or Sound mode. Make the master product the first product in the DMX daisy chain. • Configure all the slave units before connecting the master unit to the DMX daisy chain. •... -
Page 11: General Troubleshooting
Too many products connected Install an optically coupled DMX amplifier after unit #32 Terminator not connected Install a terminator. If you still experience problems after trying the above solutions, contact CHAUVET® Technical Support. Minisphere™ 3 User Manual (Rev. 4) Page 11 of 13... -
Page 12: Contact Procedure
You must send the merchandise prepaid, in its original box, and with its original packing and accessories. CHAUVET® will not issue call tags. Clearly label the package with the RMA number. CHAUVET® will refuse any product returned without an RMA number. -
Page 13: Technical Specifications
6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 7.1 in (180 mm) 7.1 in (180 mm) 6.8 in (173 mm) 1.9 lbs (0.86 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection Switching (internal)
