INSTALL INSTRUCTIONS C-TCB-3
CK-PICKUP, TAHOE, SUBURBAN, YUKON
TOOLS REQUIRED:
3/16" Allen wrench
3/8" Standard Socket Set
3/8" Metric Socket Set
HARDWARE & COMPONENTS:
QTY DESCRIPTION
1
Pole support assembly
1
Telescoping pole assembly
1
Side support brace
1
Universal support brace
1
5/16-18"Nylock nut
2
5/16"Flat washer
1
5/16-18 x 1"Hex head bolt
2
¼" x ¾"Hex head lag bolt
Telescoping pole
assembly
Pole support
assembly
Front inner passenger
seat bolt
TELESCOPING COMPUTER BASE
1995–1999 CHEVROLET/GMC
(1)-5/16-18 x 1" Hex
head bolt, (2)-
Washers, and (1)-
Nylock nut
3/8" Ratcheting Wrench
Powered drill w/ 3/16" drill bit
Open-end wrench set
PART #
CM93071-1
CM93072-3
CM93115
CM93135
GSM30017
GSM31006
GSM33012
GSM33060-1
Side support brace
(2) ¼" x ¾"Hex
Universal support
Front outer passenger
head lag bolt
brace
seat bolt mount
C-TCB-3-INST-1-05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Havis-Shields C-TCB-3
Summary of Contents for Havis-Shields C-TCB-3
- Page 1 INSTALL INSTRUCTIONS C-TCB-3 TELESCOPING COMPUTER BASE 1995–1999 CHEVROLET/GMC CK-PICKUP, TAHOE, SUBURBAN, YUKON TOOLS REQUIRED: 3/16” Allen wrench 3/8” Standard Socket Set 3/8” Metric Socket Set HARDWARE & COMPONENTS: QTY DESCRIPTION Pole support assembly Telescoping pole assembly Side support brace Universal support brace 5/16-18”Nylock nut...
- Page 2 2. Loosen or remove front inner and outer passenger seat bolts on vehicle. INSTALLATION: 1. Mount C-TCB-3 into vehicle: • Slide pole support assembly between front inner seat base mount and floor of vehicle. • Loosely attached factory seat bolt.
