INSTALL INSTRUCTIONS C-TM-F250-1
TOOLS REQUIRED:
Ratcheting wrench
Standard socket set
HARDWARE:
QTY DESCRIPTION
1
Front transmission hump bracket set
1
Rear transmission hump bracket set
1
32" Trak mount
1
Hardware kit
C-TM-F250-1 ASSEMBLY
3-Piece transmission hump
bracket
(Rear inner seat bolts)
HEAVY DUTY TRAK MOUNT
2008 F-250, 350, 450, & 550
3-Piece transmission hump
bracket
(Front inner seat bolts)
Metric socket set
T-55 Torx Socket Bit
7/16" wrench
PART #
C-B50
C-B51
C-TM-32E
C-HK
32" Extruded trak
mount
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Havis-Shields Heavy Duty Trak Mount C-TM-F250-1
Summary of Contents for Havis-Shields Heavy Duty Trak Mount C-TM-F250-1
- Page 1 INSTALL INSTRUCTIONS C-TM-F250-1 HEAVY DUTY TRAK MOUNT TOOLS REQUIRED: Ratcheting wrench Standard socket set HARDWARE: QTY DESCRIPTION Front transmission hump bracket set Rear transmission hump bracket set 32” Trak mount Hardware kit C-TM-F250-1 ASSEMBLY 3-Piece transmission hump bracket (Rear inner seat bolts) 2008 F-250, 350, 450, &...
- Page 2 Read all instructions before installing any Havis-Shields Equipment Corp products. Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes! Use hardware provided with install kit For product support, visit the Install Instructions Section of our website at http://havis.com/Installation/Installation.html...
