OWNER'S
MANUAL
MODEL NO.
12019
IMPORTANT
Read and follow all Safety
Precautions and
Instructions before
operating this equipment.
Rev.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
12026
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
FAX 660-747-8650
Blade
Mount
Kit
PHONE 660-747-8183
Made In The
USA
Advertisement
Table of Contents
Related Manuals for Swisher 12019
Summary of Contents for Swisher 12019
-
Page 1: Repair Parts
OWNER’S MANUAL MODEL NO. 12019 Blade Mount Safety IMPORTANT Assembly Read and follow all Safety Operation Precautions and Instructions before Service and Adjustment operating this equipment. Repair Parts Rev. 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 PHONE 660-747-8183 Made In The... - Page 2 Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the splitter will be needed before any warranty claim can be processed.
- Page 4 Nuts Removed Assembly Instructions Latch Assembly Unpack carton and identify parts. Note: Some of the parts have been loosely assembled for shipping. Please note the sequence of the assembly Place the Hinge plate on the Push Plate aligning the 5/8 inch hole in the Spacers removed Push plate with the 1 inch hole in the hinge plate.
- Page 5 Assembly of Blade to Push Frame Get the ½ X 1 1/2 inch Bolts, Washers, Nuts, and Spacers from the hardware bag. Place the push frame assembly against the blade assembly aligning holes A and B. Insert the Spacer into the Hole in the Hinge Plate and place the bolt through the assembly with a Washer on each side as shown.
-
Page 6: Parts List
Parts List... - Page 7 Parts List Item Part No. Description Item Part No. Description 12404TK Push Plate Painted NB275 Washer 5/16 12407TK Hinge Plate Painted 7823 Blade Spring 10161 Washer 7817 Latch Angle Bracket NB561 5/8-11 Nylock Nut 7840Z Guide Pin Bushing 7843Z Stop Block 7814Z Pin Guide NB618...
