Note
•
This product may not be compatible with certain types
of USB storage device.
•
If you use a USB extension cable, USB HUB, or USB
multi-reader, the USB storage device may not be
recognized.
•
Digital camera PTP protocols are not supported.
•
Do not remove the USB storage device while it is
being read.
•
DRM-protected music files (MP3, WMA) are not
supported.
•
Support a USB port: 5V

Auto standby

When playing media from a connected device,
the Surround Base automatically switches to
standby if:
• no button is pressed for 30 minutes, or
• no audio/video play from a connected
device (except USB) for 30 minutes.

Apply factory settings

You can reset this product to the default
settings programmed at the factory.
1
In standby mode, press and hold
on the main unit for at least 5 seconds
until the product powers on.
, 1A.
button
6 Product
specifications
Note
•
Specifications and design are subject to change without
notice.
Amplifier
• FTC total output power: 40 W
• Left: 11 W (1%THD, 4 ohm,
20 Hz - 20 kHz)
• Right: 11 W (1%THD, 4 ohm,
20 Hz - 20 kHz)
• Subwoofer: 18 W (1%THD,
4 ohm, 20 Hz - 70 Hz)
• RMS total output power: 80 W RMS
(+/- 0.5 dB, 10% THD)
• Frequency response:
20 Hz - 20 kHz / ±3 dB
• Signal-to-noise ratio:
> 65 dB (CCIR) / (A-weighted)
• Input sensitivity:
• AUX: 2 V rms
• AUDIO IN: 1 V rms
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class
(MSC)
• File system: FAT16, FAT32, NTFS
• Maximum memory support: < 64 GB
• Supports MP3 and WMA file formats
EN 11
