Summary of Contents for PQI JOY TONE - U920
- Page 1 Thank you for purchasing U920. Please read this guide carefully before using U920. Portable I-Stick Player User's Manual Contents of this manual are subject to change depending on the model type in the future. If applicable, you can download the revised version from our web site.
- Page 2 Copyright Information in this document has been carefully checked for accuracy; however, it is subject to change without notice. This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic or other means, in any form, without prior written permission of the manufacturer.
-
Page 3: Getting Started
Getting Started Before using the MP3 player, please copy “Intelligent Stick Player Font (I-Stick Player Font)” from the CD to the Intelligent Stick. You won’t have to follow the process again, if you don’t format I-Stick or delete the file. If the font is not installed, then the letters and characters will not be displayed normally. -
Page 4: Safety Information
Safety Information Read the precautions below carefully to avoid damage and loss of property. Cautions for earphones -. Traffic Safety: Do not use earphones when you are driving bicycle, automobile and motorcycle. It is not easy to hear sound from outside and it is illegal in some regions. Even though you are walking, it is dangerous when using earphones with higher volume. - Page 5 Features ● Playing back MP3/WMA music files Save and play back the WMA file of Microsoft Corporation and the MP3 file. ● Receiving and recording the FM radio Receive FM radio signal and record it digitally as an MP3 file. ●...
-
Page 6: Package Component
PACKAGE COMPONENT Check to make sure that your package contains the following items: 1.Digital Audio Player 2.Stereo Earphone 3.Program CD 4.Neck Strap 5.Manual 6.Carrying Case 7.AA Size Battery x 1 8.Intelligent Stick and Adapter ■If any of these items is missing or appears damaged, contact your vendor for immediate assistance. -
Page 7: Each Part Name
EACH PART NAME 1. Neck Strap Hole 2. Earphone Jack 3. Record Button/Sector Repetition 4. LCD 5. Volume Control Button 6. Microphone 7. Recording LED 8. Hold Key 9. Battery Cap 10. Intelligent Stick slot 11. Forward/Rewind/Menu Button 12. Play/Pause Button, Power On/Off... -
Page 8: Lcd Information
LCD INFORMATION 1. Battery Level 2. Hold 3. Repetitive Playback 4. Music Number 5. Playback Time 6. Repetition Mode 7. Sound Effect 8. Music Title/Words/Menu 9. Playback Status 10. File Type 11. Bit Rate 12. Sampling Frequency 13. Volume 14. Playback Progress... - Page 9 BATTERY a: Insert the battery with correct polarity (+/-). Check the "+/-" label inside the battery cab. b: Slide down the battery cab and lift up as shown in the figure. Low Battery Warning Full Battery Decremented Battery Low Battery Flat Battery If the flat battery icon appears as shown left, replace with new one.
-
Page 10: Operating Instructions
Operating Instructions Power On/Off Press the PLAY [▶] button for 2 seconds or longer.. The "Joytone U920" will be displayed on the LCD. Press the PLAY [▶] button for 2 seconds or longer. The "POWER OFF" message will be displayed on the LCD and the power will be turned off. - Page 11 Listening to FM radio (87.5 ~ 108.0Mhz) To convert the FM MODE, press the Menu key for 2seconds. To listen to the radio broadcasting you want (Search Mode) Move to the channel by pushing the Jog key to FF[▶▶] or REW[◀◀] direction. To move quickly, just keep on the Jog key pushing to FF[▶▶] to REW[◀◀] direction.
- Page 12 RECORDING FM RECORDING To record the FM radio broadcasting, keep on pressing REC button over 2 seconds. Press REC button to pause the FM recording shortly and push again it to continue to record. 1. STOP RECORDING Press /■(Play/Pause) button to stop the recording. ▶...
- Page 13 Press the [REC] button longer than 2 seconds. Then, the red LED will flash and voice recording will be started. Pausing voice recording Press the [REC] button during voice recording. Then, the red LED will flash and the ( ) symbol will appear. Press the [REC] button gain to resume voice recording.
- Page 14 Menu Structure when Setting Mode BROWSE PLAY MODE ●REPEAT ALL ●SEQUENTIAL ●SELECT SOUND EFFECT ●SOUND EFFECT ●TRUE BASS ●SRS WOW ●EQ ●USER EQ DISPLAY ●BACKLIGHT ●LCD CONTRAST ●SCROLL SPEED ●MENU LANG ●TAG LANG ADVANCED ●SLEEP TIMER ●STANDBY TIMER ●BATTERY ●MEMORY ●F/W VERSION RECORD ●VOICE QUALITY ●FM QUALITY ●VAD OFF/ON...
-
Page 15: Sound Effect
BROWSE Specify the range of the files to playback. Press the FF [ ▶▶ or REW [ ◀◀ key and the MENU key to select the file. Then, the file will be played back. REPEAT You can set the repetitive playback function. Press the MENU key to select the function you want. - Page 16 DISPLAY Use this function to change the display setting of JOYTONE U920. ⊙BACKLIGHT> : Sets the time duration the LCD light is on. ⊙LCD CONTRAST : Sets the LCD contrast. ⊙SCROOL SPEED: Sets scrolling speed. ⊙LANGUAGE : Selects one of Korean, English, Japanese or Chinese. ⊙TAG LANGUAGE: You can select the ID3 tag language.
- Page 17 FM RADIO ⊙STEREO / MONO MODE: Select one of the stereo or mono mode. ⊙RECEIVE LEVEL: Sets the FM reception sensitivity. ⊙BAND AREA: Sets the bandwidth area for each country. ⊙BAND STEP.. ⊙AUTO PRESET : Select this menu to scan the channels automatically. ⊙SCAN/PRESET MODE PRESET: You can select the channel you have previously entered.
-
Page 18: Troubleshooting
Troubleshooting 1. Why isn’t it the unit working or anything displayed on the LCD? ● Check the battery is inserted correctly. 2. There is no sound when the PLAY key is pressed. ● Check the MP3 files are stored in I-Stick. ●... - Page 19 Check the following items first if any problem happens. 1. Playing does not work and the LCD screen is not turned on. Check if the battery is correctly inserted. Replace the battery with new one. Charge the rechargeable battery. 2. Cannot hear any sound. Check if the memory file is saved.
-
Page 20: Specifications
Specifications Model name JOYTONE U920 Text Display LCD ID3 v1 tag, ID3 v2 tag Supports ISO MPEG 1/2/2.5 layer 3 including variable bit rate. Supports ISO MPEG 1/2/2.5 Layer 3 including variable bit-rate * MPEG1 Layer3 : 32KHz / 44.1KHz / 48KHz MP3 Decoding 32, 40, 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 Kbps MONO / STEREO / JOINT STEREO MODE... - Page 21 Note: 1. The warranty period, policy and procedure may be varied by different regions. 2. If trouble occurs, you may contact the distributor or the customer service team of PQI.
-
Page 22: Contact Information
5222 AV Den Bosch, The Netherlands Tel: 31-73-627-3555 Web: http://www.pqieurope.com Hong Kong Branch PQI (H.K.) Co., Ltd. Flat F, 4/F, Yeung Yiu Chung (No.8) Industrial Building, 20 Wang Hoi Road, Kowloon Bay, Kowloon, H.K. Tel: 852-2707-4118 E-mail: sales@pqi.com.hk Japan Branch PowerGlobal Index Co., Ltd.
