- Page 1 Portable Digital MP3 Player User Manual JoyTone U650 D I G I T A L VoicE REcord The appearance of the product may differ from the illustrations in this manual. Functions of the product are subject to change without prior notice. Please read this manual before using the product.
- Page 2 Copyright© 2004, All Rights Reserved. Trademarks PQI, the PQI logo, and the trademark are the registered trademarks of Power Quotient Interna- tional Co., Inc. and its affiliates in the United States and other countries. Windows 98, Windows 98SE, Windows ME, Windows 2000, and Windows XP are trademarks of Microsoft Corporation in the US and other countries, used under license.
- Page 3 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate, radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 4 Certification CE Notice (European Union) The symbol indicates compliance of this equipment to the European Council Directive 89/336/EEC and the Low Voltage Directive of the European Union. These markings indicate that this system meets the following technical standards: EMI: EN 55022 (1998) Class B EN 61000-3-2 (2000), EN 61000-3-3 (1995) + A1 (2001) EMS: EN 55024 (1998) + A1 (2001): IEC 61000-4-2 (1995) + A1 (1998), IEC 61000-4-3 (1995) + A1 (1998),...
-
Page 5: Warranty Information
For any unit proved to be defective within this period, PQI will, at its discretion, either repair or replace the unit, free of charge. The replacement unit will be either new or refurbished to be functionally equivalent to new, at PQI's option. - Page 6 Disclaimer PQI is not liable for damage caused by fire, natural disaster (such as lightning, earthquake, etc.), use by third parties, accidents, owner's intentional misuse, damage caused by neglect of instruc- tions described in this manual, or damage caused by misuse or malfunction through simulta- neous use of this product and connected equipment.
- Page 7 THE NETHERLANDS PQI EUROPE B.V. Helftheuvelweg 11, 5222 AV Den Bosch, The Netherlands TEL: +31-73-6273555 FAX: +31-73-6234033 www.pqieurope.com JAPAN POWERGLOBAL iNDEX CO.,LTD. Segi Bld-7F 1-7-1 Iwamoto-Cho, Chiyoda-ku Tokyo 101-0032 Japan TEL: +81-3-58354545 FAX: +81-3-58354540 www.pg-index.com CHINA (Shanghai) POWER QUOTIENT INTERNATIONAL (Shanghai) CO., LTD.
- Page 8 Room 18B, Block C, Electronic Science & Technology Building, No.2070 Shennan Zhong Road, Shenzhen, China, 518031 TEL: +86-755-83287509 FAX: +86-755-83287582 www.pqi.com.cn CHINA (Hong Kong) POWER QUOTIENT INTERNATIONAL (H.K.) CO., LTD. Flat F. 4/F, Yeung Yiu Chung (No. 8) Industrial Building, 20 Wang Hoi Road, Kowloon Bay,...
-
Page 9: Safety Warnings
Safety Warnings This section contains important health and safety information. Read it carefully before using the player. Do not expose Do not attempt to your player to disassemble, temperatures modify, or repair above 35°C or your player. below 0°C. Do not expose Do not expose your player to your player to... - Page 10 Remove the Use the neck strap battery when the with caution. It product is not in might get caught use for a long in doors and cause period of time. physical injury. Be careful. If you fall on the product while it is in your pocket, you may hurt yourself.
-
Page 11: Table Of Contents
Table Of Contents Introducing the JoyTone U650 MP3 Player ............1 Package Contents................... 2 System Requirements ..................2 Touring the JoyTone U650 MP3 Player............3 ....................3 Front View ....................4 Top View LCD Overview ....................5 ................. 5 Music Playback Mode ................ -
Page 13: Introducing The Joytone U650 Mp3 Player
Introducing the JoyTone U650 MP3 Player Thank you for purchasing the JoyTone U650 MP3 Player! The JoyTone U650 MP3 Player offers high quality audio playback and voice recording functions at low power consumption. The JoyTone U650 MP3 Player supports the MP3 music format for your listening pleasure. -
Page 14: Package Contents
Package Contents Check the contents of your JoyTone U650 MP3 Player package. Contact your dealer immedi- ately if any of the following accessories are missing or damaged. • JoyTone U650 MP3 Player • Earphones/FM radio with volume control • One 3.4V button-type battery for earphones •... -
Page 15: Touring The Joytone U650 Mp3 Player
Introducing the JoyTone U650 MP3 Player Touring the JoyTone U650 MP3 Player The following section describes the various components of the JoyTone U650 MP3 Player. Front View The front view of this product is shown below: Item Description Function Neck strap hook Attach a neck strap to carry the player. -
Page 16: Top View
Top View The top view of this product is shown below: Item Description Function Menu/MODE jog dial Selects various menu options − button Decreases the volume + button Increases the volume Display button/HOLD Toggles the display between playback and file or firmware information... -
Page 17: Lcd Overview
Introducing the JoyTone U650 MP3 Player LCD Overview Music Playback Mode This mode plays the MP3 songs stored on the player. 001/001 MUSIC A -B 128KBPS CLASS 02:49 Connie Francis Item Description Function Mode Indicates the mode of operation Current track Indicates the number of the song being played Total number of tracks Indicates the total number of songs stored in the device... -
Page 18: Voice Recording Mode
Voice Recording Mode This mode records voice from the built-in microphone. 000/055 Mi c: H V OR 56KBPS 00:00:34 AUDIO002.MP3 Item Description Function Mode Indicates the mode of operation Current recorded file Indicates the number of the voice recording being played Total number of recordings Indicates the total number of recordings stored in the... -
Page 19: Getting Started
Getting Started Inserting a Battery in the Player Pull out the USB Cover in the Notes: • Ensure that the polarity is correct when inserting a direction shown in the illustra- battery. tion. • Remove the battery when the player is not in use for a Open the battery compartment long time, to avoid damage by corrosion. -
Page 20: Connecting The Earphones
Connecting the Earphones Plug the earphones into the earphone jack on the player. Connecting the JoyTone U650 to a PC Connect the JoyTone U650 to your PC by plugging it into the PC’s USB port or a USB hub. When the JoyTone U650 is successfully connected to the PC, a new Removable Disk icon appears in the My Computer window on your PC. -
Page 21: Using The Player
Using the Player This section describes how to use the JoyTone U650. Turning the JoyTone U650 On and Off Press the power button for a second to turn on the JoyTone U650. After the welcome note is dis- played, the JoyTone U650 enters MP3 playback mode automatically. If there are files on the JoyTone U650, the titles of these files are displayed on the screen. -
Page 22: Playing Mp3 Music Files
Playing MP3 Music Files Follow these steps to start listening to your favorite music on the JoyTone U650 MP3 Player. 1. Turn on the JoyTone U650. 2. Press the MODE jog dial to enter system mode. Rotate the MODE jog dial to select MP3 Mode and then press the MODE jog dial to confirm. -
Page 23: Repeat Play
Using the Player Repeat Play Use the repeat function to play a selected track, section, all files, or a random file repeatedly. 1. Press and hold the MODE jog dial for two seconds. A popup menu appears. Repeat mode icon 002/002 VOICE A- B... -
Page 24: A-B Repeat
A-B Repeat This repeat function is used to repeat a section of the currently playing song. The following is the procedure to repeat a section of the currently playing song: 1. Play the song and mark the A-B repeat icon beginning of the section to be repeated by pressing the jog dial for less than 2 sec-... -
Page 25: Selecting An Eq Mode
Using the Player Selecting an EQ Mode The JoyTone U650 provides five equalizer modes (EQ) to enhance audio quality. Follow these steps to select the EQ mode. 1. Press and hold the MODE jog dial for two seconds. A popup menu appears. EQ mode icon 002/002 VOICE... -
Page 26: Using The Recorder Function
Using the Recorder Function Follow these steps to record your voice using the built-in microphone. Note: The Recording function is disabled when the battery is low. 1. Press the MODE jog dial to enter system mode. 2. Rotate the MODE jog dial to select REC Mode and then press the MODE jog dial to con- firm. -
Page 27: Setting Recording Parameters
Using the Player Setting Recording Parameters Follow these steps to set recording parameters: 1. After selecting REC Mode, press the MODE jog dial for two seconds to display the parameter menu. 002/002 Mic:H 16KBPS 00:00:00 Sen. 2. Set the desired options as described in the following table: Parameter Possible Values Description... -
Page 28: Playing Back Recorded Voice Files
Playing Back Recorded Voice Files VOICE mode enables you to play back your voice recordings. All recordings are saved as MP3 files with a filename such as AUDIO001.MP3. The number at the end of the filename indicates the order in which the recordings were saved. Follow these steps to listen to your recorded voice files. -
Page 29: Deleting Files From The Joytone U650
Using the Player A -B 128KBPS CLASS 00:00 AUDIO001.MP3 Note: The repeat play and equalizer functions are also available when you play back a recording. Refer to “Repeat Play” on page 11 and “Selecting an EQ Mode” on page 13 for more details. Deleting Files from the JoyTone U650 Follow these steps to delete files from the JoyTone U650. - Page 30 The following menu is displayed: 5. Rotate the MODE jog dial to select a desired delete option. 6. Press the MODE jog dial to confirm your selection. Notes: • The Delete all files option deletes all files while the delete one file option deletes the currently dis- played file.
-
Page 31: Troubleshooting
Troubleshooting Please refer to the following if there are problems with the player. Symptom: No power Check that the battery is inserted correctly. Symptom: No sound • Check that the earphone is connected to the earphone jack. • Check that the volume is not at 0. Symptom: Noise •...
