1" AIR IMPACT WRENCH
Model 92427
ASSEMBLY and OPERATING
INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
®
Copyright © 2004 by Harbor Freight Tools
. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Central Pneumatic 92427
Summary of Contents for Central Pneumatic 92427
- Page 1 . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts, please call 1-800-444-3353...
-
Page 2: Specifications
Dress properly. Do not wear loose clothing or jewelry as they can be caught in moving parts. Protective, electrically nonconductive clothes and nonskid footwear are recommended when working. Wear restrictive hair covering to contain long hair. SKU 92427 For technical questions, please call 1-800-444-3353 Specifications 1450 Ft. - Page 3 Check your air compressor’s manual for the appropriate size cord. 19. Maintenance. For your safety, maintenance should be performed regularly by a qualified technician. 20. Compressed air only. Never use combustible gas as a power source. SKU 92427 For technical questions, please call 1-800-444-3353 Page 3...
-
Page 4: Air Connection
When unpacking, check to make sure the parts listed on page 8 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible. -
Page 5: Operation
Failure to operate the Impact Wrench with two hands may result in serious, permanent injury. See FIGURE 3 below. FIGURE 2 Anvil (43) FIGURE 3 Proper way to hold the Impact Wrench SKU 92427 For technical questions, please call 1-800-444-3353 Assembly Securing with the two Screws (49) Operation Handle (48) Air Coupler... - Page 6 Always check the recommended torque specification for the nut. Use a torque wrench to tighten the nut to the proper setting after using the Impact Wrench. SKU 92427 For technical questions, please call 1-800-444-3353 Operation (continued) Forward...
-
Page 7: Maintenance
Replace the Oil Screw (22). Note: A second oil plug, not shown here, is located at the front end of housing. SKU 92427 For technical questions, please call 1-800-444-3353 Operation (continued) Maintenance Oil Screw (22) Page 7... -
Page 8: Parts List
OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 92427 For technical questions, please call 1-800-444-3353 Parts List Qty. -
Page 9: Assembly Drawing
Assembly Drawing Note: The Wrench (54) is not shown. SKU 92427 For technical questions, please call 1-800-444-3353 Page 9...
