4. Attach the unit to the mounting bracket.
(2) Remove the numeric
keyboard.
5. Connect the coaxial cable to the unit.
The unit is connected to the control unit (Camera 1 - 3).
Coaxial cable
6. When you use the built-in CCTV camera, connect the
supplied video output cable to VIDEO OUT. Then, con-
nect the supplied video output cable and the video
input cable of a connected device (for example, moni-
tor or DVR).
Connect them.
10
(1) Attach the mounting
bracket to the wall.
Screw nut (M5)
To CAMERA 1 - 3 of the control unit
Pass the cable
through this hole.
To a monitor or Digital Disk Recorder
Video output cable and
power cable *
(from the control unit)
(3) Remove the shipping lock.
(4) Attach the unit to the mounting bracket.
Secure the unit and bracket with the screw nut,
using an 8 mm (0.03 in.) socket driver.
(5) Connect the cables to the unit.
(6) Attach the numeric keyboard.
* Refer to the control unit's operating instructions
for the specifications.
7. Connect the DC power cable to the unit.
If you use power supply from the control unit to the unit,
connect the DC power cable to 0 V and +32 V ports.
If you use 24 V DC power supply from an external
power-control device, connect the power cable to 0 V
and +24 V ports.
0 V +24 V +32 V
Caution: Take DC 24 V power supply from a third-party
external power supply device that complies with the
safety standard.
(Refer to p.18.)
Provide access for
cables to be routed
through the wall.
Pass the cable
through this hole.
To the control unit
