Summary of Contents for Whynter CUF-210SS
- Page 1 WHYNTER 2.1 cu. ft. UPRIGHT FREEZER MODEL # : CUF-210SS Instruction Manual Congratulations on your new WHYNTER product. To ensure proper operation, please read this Instruction Manual carefully before using this product. Keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Part and Features Safety Precautions Electrical Requirements Installation Leveling the upright freezer Reversing the door swing Operation Defrosting Cleaning and maintenance 10 - 11 Energy Saving Tips Troubleshooting Warranty Information... -
Page 3: Part And Features
PARTS AND FEATURES Cabinet Compressor mounting panel Bottom hinge Door Door seal Powder-coated steel wire shelf Powder-coated steel wire shelf Leveling leg Smaller bottom hinge leveling leg 10. Top hinge 11. Top hinge cover 12. Lock 13. Thermostat control knob... -
Page 4: Safety Precautions
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY WHEN USING YOUR WARNING FREEZER, FOLLOW THESE BASIC PRECAUTIONS: READ ALL INSTRUCTIONS BEFORE USING THE FREEZER. WARNING: RISK OF DANGER TO SMALL CHILDREN AND SMALL ANIMALS. ENTRAPMENT AND SUFFOCATION DANGER IF NOT PROPERLY SECURED. DISPOSED OR ABANDONED APPLIANCES ARE STILL DANGEROUS ... -
Page 5: Electrical Requirements
ELECTRICAL REQUIREMENTS Electrical Shock Hazard Plug into a grounded 3-prong outlet. Never remove the grounding prong from the plug. We strongly recommend against the use of an extension cord. However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts. -
Page 6: Installation
INSTALLATION Excessive Weight Hazard Two or more people should move and install upright freezer. Failure to do so can result in back or other injury. Remove packaging materials IMPORTANT: Do not remove any permanent instruction labels or the data label on your upright freezer Remove tape and glue from your upright freezer before using ... -
Page 7: Leveling The Upright Freezer
adequate ventilation and access for service. Never install or operate the unit in an enclosed area, such as a closed cabinet. Before connecting the upright freezer to the power source, let it stand upright for approximately 4 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. - Page 8 1．Start by removing the bottom hinge from the bottom of the freezer. Unscrew the two screws from the bottom hinge. Remove the foot from opposite side. Slide the door down, away from the hinge pin located on the top of the door.
-
Page 9: Operation
OPERATION To obtain the best possible results for your upright freezer, it is important that you operate it properly. Temperature Control The temperature in the upright freezer is controlled by the thermostat control knob. The thermostat control box is located in the compressor compartment at the back of the unit. To operate this control, turn the thermostat control knob up or down to regulate the temperature inside the upright freezer. -
Page 10: Defrosting
CLEANING AND MAINTENANCE Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is disconnected. Do not touch the power plug when your hands are wet. Never unplug the unit by pulling on the plug. Defrosting Note: To avoid damaging the freezing compartment wall, never use a sharp or metallic instrument to scrape off frost or separate the frozen food. -
Page 11: Energy Saving Tips
CAUTION The upright freezer must be thoroughly cleaned if it has been left unused for a long time. PROLONGED OFF PERIODS If the upright freezer is not to be used for a long period of time, please disconnect unit from main power supply. -
Page 12: Troubleshooting
TROUBLESHOOTING Many common upright freezer problems are easily resolved. Try the troubleshooting suggestions below to see if the problems can be resolved before having to contact the service department. Problem Possible Cause Probable Correction The upright freezer is unplugged. Plug the upright freezer in. -
Page 13: Warranty Information
ONE YEAR LIMITED WARRANTY This Whynter Upright Freezer is warranted, to the original owner within the 48 continental states, for one year from the date of purchase against defects in material and workmanship under normal use and service. Should your upright freezer prove defective within one year from the date of purchase, return the defective part or unit, freight prepaid (within two months of purchase;...
