Function buttons and external sockets

Front and side panel of the TV set

Side-set terminals
Video1 input
terminal
Left sound
track
Right sound
track
MENU
Volume up/ down
TV/Video
(input selector

Rear panel of the TV set

Video output terminals: VIDEO AUDIO L, R
Video 2 input terminals: VIDEO AUDIO
DVD input terminals: Y, Cb, Cr
If you want to connect the TV set to the other audio/video equipment, please
refer to P22.
Channel selector
S-VIDEO
S-VIDEO input terminal
L, R
AUDIO L, R
Power switch
Infrared sensor window
Power indicator
Antenna input
