- Page 1 SM Pro Audio Operating Manual - SM HP6 6 Channel Headphone Amplifier Manual Version 1.2 Jan 2006 www.SMProAudio.com...
- Page 2 SAFETY INSTRUCTIONS CAUTION: To reduce the risk of electrical shock, do not remove the cover or rear panel of this unit. No user serviceable parts inside. Please refer servicing to qualified personnel only. WARNING: To reduce the risk of fire or electrical shock do not expose this appliance to rain or moisture.
- Page 3 Thank you very much for expressing your confidence in SM Pro Audio products by purchasing this unit. The SM HP6 has been designed to be used as a standard tool for home/pro studios, P.A. rental companies etc. With much experience in the audio industry over a long period of time, and along with valuable suggestions from our customers, our engineers have developed a pro duct we know you will be satisfied with.
-
Page 4: Table Of Contents
4.1 Independent (4 x) rotary signal selector switches for each headphone amplifier 4.2 Independent (6 x) rotary volume pot controls for each headphone amplifier output 5. APPLICATION 5.1 Using the SM HP6 as a headphone amplifier 6. SPECIFICATIONS 7. WARRANTY... -
Page 5: Introduction
1. INTRODUCTION In purchasing the new SM HP6, you have acquired a headphone amplifier of high class that meets all the demands and requirements of studio and live work. Due to its extensive functions the SM HP6 is an extremely efficient and universal headphone amplifier. It has been designed above all as a reference unit for musicians in the studio. -
Page 6: Installation
3.3 Audio connections Analog inputs - On the rear of the SM HP6 there are 8 (4 x stereo pair) 1/4 inch line level audio jacks which will accept 4 x stereo (L&R) input signals. Stereo headphone outputs - On the front of the SM HP6 there are 6 x stereo 1/4 Inch output jacks for connection of 6 x stereo headphone sets. -
Page 7: Application
5.1 Using the SM HP6 as a headphone amplifier Connect a stereo (L&R) program source (2 x 1/4” inch Jacks) to the rear of the SM HP6 using one of the available 4 x stereo input pairs on the rear panel. -
Page 8: Specifications
Net weight approx. 3.15 kg SM Pro Audio is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or shown. -
Page 9: Warranty
To be protected by this warranty, the buyer must complete and return the enclosed warranty card (signed/stamped by retail dealer) within 14 days of the date of purchase to SM Pro Audio (see address below 3). Failure to return the card in due time (date as per postmark) will void any extended warranty claims. - Page 10 The warranty does not cover any such modification/adaptation, irrespective of whether it was carried out properly or not. Under the terms of this warranty, SM Pro Audio shall not be held responsible for any cost resulting from such a modification/adaptation.
- Page 11 SM Pro Audio. 6 CLAIM FOR DAMAGES Failure of SM Pro Audio to provide proper warranty service shall not entitle the buyer to claim (consequential) damages. In no event shall the liability of SM Pro Audio exceed the invoiced value of the product.
