Features and Functions
VERTICAL AIR DIRECTION ADJUSTMENT
Press the AIR FLOW DIRECTION VERTICAL SET button.
Each time the button is pressed, the air direction range will change as follows:
Cool/Dehumidification/Fan:
1
Heat:
5
Use the air direction adjustment within the ranges shown above.
The vertical airflow direction is set automatically as shown, in accordance with the type of
operation selected.
HORIZONTAL AIR DIRECTION ADJUSTMENT
Press the AIR FLOW DIRECTION HORIZONTAL SET button.
Use the air direction adjustments within the ranges shown above.
2 3
4 3
5
5
4
3
2
1
4 5
2 1
1
2
3
4
6
