Summary of Contents for Hafler IRIS COMPACT DISC PLAYER
- Page 1 OWNER’S MANUAL IRIS COMPACT DISC PLAYER IRIS COMPACT DISC PLAYER A Division of Rockford Corporation 613 South Rockford Drive Tempe, Arizona 85281 602 - 967 - 3565...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ......Page 1 Installation Set-Up ......Connections . -
Page 3: Introduction
INTRODUCTION The Hafler IRIS system is a major step forward in the world of audio technology. The IRIS CD completes an intensive engineering effort to create a series of components which offer superior performance combined with the unprece- dented convenience of the IRIS remote control. -
Page 4: Connections
WARNING- Never allow the player to stand for long periods in direct sunlight or near any heat source. CONNECTIONS REMOTE CONTROL The IRIS CD has two recessed male connectors on the back panel. allow the IRIS digital data-bus to “daisy-chain” to other IRIS-compatible accessories. - Page 5 DISPLAY Indicates the player’s present function. Displays details from the disc contents list. The indications on the display are detailed in Figure 3. PLAY button For starting play (PLAY). For returning to the beginning of a track (REPLAY). STOP button For stopping play.
- Page 6 This tells the Preamplifier, when CD is selected, to automatically “transfer” the remote’s top eight (multi- legend) keys to perform CD command functions. All of the KEY functions of the CD Player panel which are convenient from remote operation are available from the 8 remote KEYS:...
-
Page 7: Clear Key
CLEAR KEY The CLR (CLeaR) key on the remote transmitter causes the CD Player to stop and allows selection of another input source to the IRIS Preamp within 3 seconds. If another source is not selected within three seconds, the remote’s key functions will remain in CD mode. - Page 8 1 ’ . 9 ---’ Lights up when the player is switched on. Flashes during scanning of the disc contents list. 2. TRACK The number of the track which is currently playing. The number of tracks on the disc when the tray is closed with the OPEN/CLOSE button.
-
Page 9: Loading The Disc
LOADING THE DISC Open the disc tray by pressing OPEN/CLOSE. Insert the disc into the tray printed side up. Handle disc by edges only - do not touch the surface. To close the tray: Press the front of the tray lightly or OPEN/CLOSE, or press PLAY, to simply play the disc. -
Page 10: Selecting Another Track During Play
GOING BACK TO THE BEGINNING OF A TRACK (REPLAY) Press PLAY The current track starts again from the beginning. SELECTING ANOTHER TRACK DURING PLAY SELECTING A HIGHER TRACK NUMBER Press )1 (NEXT) until the desired track number appears on the display. The playing time indication disappears. - Page 11 SEARCHING FOR A PARTICULAR PASSAGE DURING PLAY Hold << (SEARCH) down to search backward to the begin- ning. Hold >> (SEARCH) down the search forward to the end. As soon as the button is released play restarts at once. The length of time for which the button is held down determines the search speed: - The first three seconds searching is relatively slow.
-
Page 12: Checking The Program
Press PRG - The PROGRAM indicator will light up and the display will indicate Go back to ‘3.’ using H (PREVIOUS) Press PRG again You will now see ‘3P’. Continue this sequence until track 10 has been stored. When the last number has been stored the display will show ‘10P’... -
Page 13: Additional Information
PLAYING THE PROGRAM Press PLAY - Pressing H (PREVIOUS) or H (NEXT) during All player functions can be used during programmed play except Searching for a particular passage is limited to within the track being played. When either end of the track is reached ERROR lights up. - Page 14 POWER For switching on and off OPEN/CLOSE: Open and close the disc tray PLAY. Starts play or returns to track beginning S T O P S t o p s o r e r a s e s a p r o g r a m PAUSE: Briefly i n t e r r u p t o r r e t u r n f r o m i n t e r r u p t e d SHF: Play all tracks on a disc in random order...
- Page 15 PROGRAM: Indicates storage of the first track of a program TRACK: Indicates number of track playing PAUSE: Indicates pause mode TIME: Indicates playing time i n m i n u t e s a n d s e c o n d s a REPEAT: Indicates S H U F F L E : I n d i c a t e s p l a y i n g d i s c i n r a n d o m o r d e r...
-
Page 16: Player Maintenance
edge. You may breathe lightly on the disc first, to provide slight Warning: Cleaning agents for conventional vinyl records are not suitable for cleaning a Compact Disc, nor may detergents or abrasive cleaning agents be used. PLAYER MAINTENANCE When cleaning the player and face-plate, we advise a soft cotton cloth with a non-abrasive cleaner that is safe for Lexan and painted surfaces. -
Page 17: Symptoms And Their Likely Causes
FACTORY SERVICE AND LIMITED WARRANTY If you encounter any difficulty or have any questions con- cerning you IRIS CD player, please call our Customer Service weekdays, 8 am to 3:30 pm Mountain Standard time, at 602-967-3565. Before returning any unit to the factory for service, please call us. - Page 18 The Hafler IRIS CD Player is warranted for 1 year from the date of purchase, including parts, labor, and return ship- ping costs from the factory to the owner within the Con- tinental USA.
