Grizzly H8145 Owner's Manual

Baby table saw

Hide thumbs Also See for H8145:

Parts breakdown (3 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

MODEL H8145

BABY TABLE SAW

OWNER'S MANUAL

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#TRJC8950 PRINTED IN CHINA

Table of Contents

Need help?

Do you have a question about the H8145 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grizzly H8145

Page 1 MODEL H8145 BABY TABLE SAW OWNER'S MANUAL COPYRIGHT © JANUARY, 2007 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #TRJC8950 PRINTED IN CHINA...
Page 2 �� ...
Page 3: Table Of Contents
INTRODUCTION ... 2 Foreword ... 2 Contact Info ... 2 Machine Data Sheet ... 3 Identification ... 4 SECTION 1: SAFETY ... 5 Safety Instructions for Machinery ... 5 Safety Instructions for Table Saws ... 7 Preventing Kickback ... 8 Protecting Yourself From Kickback ...
Page 4: Introduction
INTRODUCTION Foreword We are proud to offer the Model H8145 Baby Table Saw. This machine is part of a growing Grizzly family of fine woodworking machinery. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of Grizzly’s com-...
Page 5: Machine Data Sheet
�� H8145 Baby Table Saw �� ...
Page 6: Identification
Identification Figure 1. H8145 identification. A. Fence Lock Knob (1 of 2 shown) B. Fence C. Blade Guard D. Riving Knife E. Front and Rear Fence Scales ON/OFF Switch G. Push Stick Holder Clips H. Blade Tilt Scale Blade Tilt Lock Handle (1 of 2 shown)
Page 7: Section 1: Safety
�� H8145 Baby Table Saw �� ...
Page 8 �� H8145 Baby Table Saw...
Page 9: Safety Instructions For Table Saws
Like all machines there is danger associ- ated with the Model H8145. Accidents are frequently caused by lack of familiarity or failure to pay attention. Use this machine with respect and caution to lessen the pos- sibility of operator injury.
Page 10: Preventing Kickback
If a kickback occurs, the push stick will most likely take the damage that your hand would have received. • Use featherboards or anti-kickback devices to prevent or slow down kickback. H8145 Baby Table Saw...
Page 11: Glossary Of Terms
The following is a list of common definitions, terms and phrases used throughout this manual as they relate to this table saw and woodworking in general. Become familiar with these terms for assembling, adjusting or operating this machine. Your safety is VERY important to us at Grizzly! Arbor: A metal shaft extending from the drive mechanism that is the mounting location for the saw blade.
Page 12: Section 2: Circuit Requirements
DO NOT connect the machine to the power source until instructed to do so. Amperage Draw The Model H8145 motor draws the following amps under maximum load: Motor Draw ... 3 Amps Circuit Recommendations...
Page 13: Section 3: Set Up
Wear safety glasses dur- ing the entire set up pro- cess! Unpacking The Model H8145 was carefully packed when it left our warehouse. If you discover the machine is damaged after you have signed for delivery, please immediately call Customer Service at (570) 546-9663 for advice.
Page 14: Dust Collection
Dust Collection DO NOT operate the Model H8145 without an adequate dust collection system. This saw creates substantial amounts of wood dust while operating. Failure to use a dust collec- tion system can result in short and long-term respiratory illness.
Page 15: Section 4: Operations
OMMEND that you read books, trade maga- zines, or get formal training before begin- ning any projects. Regardless of the con- tent in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training. H8145 Baby Table Saw Basic Controls ON/OFF Switch: Starts and stops the motor.
Page 16: Blade Selection
�� Figure 10. Combination blade. Laminate blade features: • Best for cutting plywood or veneer. • 40-80 teeth. • Triple chip tooth profile. • Very shallow gullet. �� Figure 11. Laminate blade. H8145 Baby Table Saw...
Page 17: Fence Setup
Figure 12. Figure 12. Fence setup for standard cutting. H8145 Baby Table Saw Miter Cutting For this type of cutting, the fence is setup facing away from the blade, as shown in Figure 13. This position is required to use the miter sled for 45°...
Page 18: Workpiece Inspection
Safety precautions and instructions for each type of cut are located on the following pages: Ripping: Page 17 Crosscutting: Page 18 45° Miter Cuts: Page 18 Blade Tilt/Bevel Cuts: Page 19 H8145 Baby Table Saw...
Page 19: Ripping
H8145 Baby Table Saw Turn the saw ON. Place the flat edge of the workpiece against the fence.
Page 20: Crosscutting
Figure 15. Figure 15. Typical 45° miter cut. Turn the saw ON. Hold the workpiece firmly in the miter sled, and slide the miter sled along the fence, feeding the workpiece completely through the blade. H8145 Baby Table Saw...
Page 21: Blade Tilt/Bevel Cuts
Pointer Tilt Scale Figure 16. Tilt scale and pointer. Tighten the front and rear lock handles to lock the blade in place. H8145 Baby Table Saw Changing Blade Tools Needed • Arbor Wrench 19mm ... 1 •...
Page 22: Section 5: Accessories
This high impact plastic Saw Aid™ quickly mea- sures blade height and angle and can also serve as a solid push stick. Includes a graduated ruler guide and center finder. Figure 22. G3445 Precision Saw Tool. H8145 Baby Table Saw H1298 H0736...
Page 23: Section 6: Maintenance
Cleaning Cleaning the Model H8145 is relatively easy. Vacuum excess wood chips and sawdust, and wipe off the remaining dust with a dry cloth. If any resin has built up, use a resin dissolving cleaner to remove it.
Page 24: Section 7: Service
2. Replace dented fan cover; replace loose/damaged fan. 3. Replace warped, bent, or twisted blade; resharpen dull blade. 4. Replace feet. 5. Tighten/replace. 6. Test by rotating shaft; rotational grinding/loose shaft requires bearing replacement. H8145 Baby Table Saw...
Page 25: Calibrating Blade Tilt Pointer
Calibrating Blade Tilt Pointer The blade tilt pointer is fastened to the table saw body with the hex nut shown in Figure 23. A 6mm wrench is required to loosen the hex nut to adjust the pointer.
Page 26: Riving Knife Alignment
— When working correctly, the blade guard should drop down to the closed position when released. —If the blade guard does not drop down into the closed position when released, repeat Steps 2 & 3. ⁄ turn. H8145 Baby Table Saw...
Page 27: Electrical Components
Electrical Components Switch Wiring Motor Wiring -25- H8145 Baby Table Saw...
Page 28: Wiring Diagram
�� H8145 Baby Table Saw...
Page 29: Parts Breakdown
�� H8145 Baby Table Saw Parts Breakdown �� ...
Page 30: Parts List
TAP SCREW M3-.5 X 16 PH8145061 WIRE PLATE PH8145062 PW02M FLAT WASHER 5MM PH8145064 TAP SCREW M5-.8 X 10 PAW03M HEX WRENCH 3MM PH8145066 BLADE TILT POINTER PH8145067 SPECIAL SCREW M4-.7 PH8145068 WRENCH 8MM PFS07M FLANGE SCREW M5-.8 X 10 H8145 Baby Table Saw...
Page 31: Safety Label Parts Breakdown
MUST maintain the original location and readability of the labels on the machine. If any label is removed or becomes unreadable, REPLACE that label before using the machine again. Contact Grizzly at (800) 523-4777 or www.grizzly.com to order new labels. H8145 Baby Table Saw...
Page 32: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
Page 33 �� ...
Page 34 �� ...
Page 36 �� ...
