VHF MARINE RADIO
MR F80B
Comes Close to a Cobra
®
Introduction
Thank you for purchasing a CobraMarine
Properly used, this Cobra
many years of reliable service.
Owner's Manual
How Your CobraMarine VHF Radio Works
This radio is a VHF transceiver for fixed mounting on your boat. It gives you 2-way
vessel-to-vessel and vessel-to-shore station communications, primarily for safety
and secondarily for navigation and operational purposes. With it, you can call for
help, get information from other boaters, talk to lock or bridge tenders and make
radiotelephone calls to anywhere in the world through a marine operator.
Besides 2-way communications, in the U.S.A., the radio can provide quick
access to receive all NOAA (National Oceanographic and Atmospheric
Administration), including two Canadian weather channels for alerting you to
weather emergencies with a tone on a weather channel you can select for your area.
Customer Assistance
Customer Assistance
Should you encounter any problems with this product, or not understand
its many features, please refer to this owner's manual. If you require further
assistance after reading this manual, Cobra Electronics offers the following
customer assistance services:
For Assistance in the U.S.A.
24 hours a day, seven (7) days a week 773-889-3087 (phone).
8:00 a.m. to 6:00 p.m. Central Time Mon. through Fri. (except holidays)
773-889-3087 (phone).
Faxes can be received at 773-622-2269 (fax).
www.cobra.com (online: Frequently Asked Questions).
English and Spanish. productinfo
For Assistance Outside the U.S.A.
A1 English
Our Thanks to you and
Customer Assistance
®
product will give you
English only.
English and Spanish
English and Spanish
English only.
cobra.com (e-mail).
@
®
VHF radio.
© 2007 Cobra Electronics Corporation™
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
