Page 1: Mosfet Power Amplifiers
MOSFET POWER AMPLIFIERS Installation Instructions / Owner's Manual MDS GP2 MDS GP3 MDS GP4 MDS - Multi Dynamic Systems of Sweden AB Midsommarv. 8-10 126 35 Hägersten +46(08)556 00 740 www.mds.se... - Page 3 Congratulations on your purchase of a MDS state-of-the-art power amplifier. Your selection of a MDS product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your MDS amplifier in a new system, you are certain to notice immediate performance benefits.
-
Page 4: Safety Precautions
AFETY PRECAUTIONS Fuse amplifiers power wire at the battery. Be sure to fuse the power wire within 12” of the car's battery. This will protect the car's battery in case of a short circuit between the power amplifier and battery. THIS IS A MUST, the amplifier's built-in fuse will only protect the power amplifier not the car's battery! Use high grade wire connectors. -
Page 5: Features And Benefits
Built-in Crossover The MDS amplifiers include a built-in variable **high and low pass crossovers. The crossover features a variable frequency selection (40Hz ~ 400Hz) for precise high or low pass filtering. - Page 6 Power Fusing This protects the amplifier against short circuits and excessive current. Remote Turn-on Automatically turns amplifier on when connected to the head unit's remote output. The amplifier will turn on and off with the head unit to save current consumption. This control also operates the reset circuit for the amplifier's protection.
-
Page 7: Mounting Location
OUNTING LOCATION Before you start the installation, it will be necessary to find a mounting location for the amplifier. Find a location in which the amplifier will receive adequate ventilation in order to dissipate the heat it develops during operation. Two popular mounting locations are in the trunk or under the seat. -
Page 8: Power Connections
OWER CONNECTIONS FUSE POWER SPEAKERS +12V BRIDGE IN-LINE POWER FUSE IN-LINE POWER FUSE MOUNTED WITHIN 12" MOUNTED WITHIN 12" FROM BATTERY RECOMMENDED FROM BATTERY RECOMMENDED (NOT PROVIDED) (NOT PROVIDED) RADIO'S REMOTE RADIO'S REMOTE TURN-ON OUTPUT TURN-ON OUTPUT CAR BATTERY CAR BATTERY 94.7 94.7 +12V... -
Page 9: Signal Connections
IGNAL CONNECTIONS Connect the RCA output of the head unit (AM/FM cassette player, CD, or DAT) to the RCA input terminals of the amplifier. To make these connections, we recommend high quality RCA cables, which are available at your local car audio retailer. Run signal wires away from electrical wires to avoid possibility of induced noise from the car's electrical system (i.e. - Page 10 IGH LEVEL CONNECTIONS (OPTIONAL) High Level inputs have been included to connect the amplifier to a radio without low-level outputs (i.e. factory radio). This connection will allow you to connect directly to the speaker output of the radio with out the need of an external adapter. Determine the type of radio you have and make one of the following connections.
- Page 11 INPUT HI-INPUT REAR HI-INPUT REMOTE FRONT OUTPUT POWER PROTECT GAIN GAIN + R - X-OVER X-OVER BASS BOOST BASS BOOST FILTER FILTER 40Hz 400Hz 40Hz 400Hz FULL FULL 12dB 12dB 94.7 94.7 LEFT LEFT GREEN GREEN GRAY/BLACK GRAY/BLACK RIGHT RIGHT RIGHT RIGHT LEFT...
-
Page 12: Speaker Connections
PEAKER CONNECTIONS Make the speaker connections using speaker wire that is at least 16 gauge or heavier. As with any audio component, proper phasing of the amplifier and speakers is essential for strong bass response. When connecting, make sure that positive (+) from the amplifier is connected to the positive (+) of the speaker, and the same for negative (-). - Page 13 PEAKER CONNECTIONS (BRIDGED) The MDS amplifiers are capable of being bridged in a mono configuration. This feature allows you the flexibility of using the amplifier to drive a ** subwoofer or a center channel. In this configuration the amplifier sums the right and left channel to deliver one channel (mono) output.
- Page 14 4 Ohm connections. If you wish to use multiple speakers to achieve a lower impedance and higher power, it is strongly recommended that you seek professional advice from your MDS retailer before attempting to make these connections.
- Page 15 EMOTE BASS CONTROL MODULE (OPTIONAL) Before connecting the remote, it will be necessary to find a mounting location that will be easy to access for adjustment. Once you select your mounting location, you will need to run the control wire from the remote to the amplifier. To avoid possibility of induced noise from the car's electrical system (i.e.
- Page 16 DJUSTING THE X-OVER AND BASS (Please note: If you intend to use the amplifier in the Tri-mode configuration, it is necessary to set the crossover control to the “FULL” setting in order to receive full range output) The amplifiers are equipped with a built-in variable crossover network allowing you to select the crossover type (i.e.
-
Page 17: Troubleshooting The System
ROUBLE SHOOTING THE SYSTEM We have put together this trouble-shooting guide if you experience problems after installing the amplifier. Please keep in mind that the majority of problems incurred are caused by improper installation and not the equipment itself. In addition, there are many components in the system that could cause various signal problems such as inducted electrical noise and engine noise. -
Page 18: Specifications
PECIFICATIONS MDS GP2 MDS GP3 MDS GP4 Output Power @ 14.4 VDC : Max Output 100W x 2 max 240W x 2 max 140W x 4 max 4 ohm 50W x 2 120W x 2 70W x 4 2 ohm... - Page 20 MDS - Multi Dynamic Systems of Sweden AB Midsommarv. 8-10 126 35 Hägersten +46(08)556 00 740 www.mds.se www.extremeconcepts.com MDS AMP REV 1.31.04...
