Summary of Contents for Teltonika MVC200

  • Page 1 TELTONIKA 3G Mobile Camera MVC200 User’s Manual v1.02...
  • Page 2: Legal Notice

    LEGAL NOTICE Copyright © 2010 TELTONIKA Ltd. All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of TELTONIKA Ltd is prohibited. Other product and company names mentioned herein may be trademarks or trade names of their respective owners.
  • Page 3 Ground Global System for Mobile communications Line Motion Detection Neutral Personal computer Protective earth Personal Identification Number Point-to-Point Protocol Subscriber Identity Module TCP/IP Transmission Control Protocol/Internet Protocol World Wide Web Teltonika © 2010 All Rights Reserved P a g e...
  • Page 4: Table Of Contents

    3.7.1 Motion Detect ..............................25 3.7.2 AlarmIn ................................25 3.7.3 AlarmOut ................................ 26 Record................................26 3.8.1 Schedule (local SD card) ..........................26 3.8.2 Network Storage ............................27 Playback ................................28 Teltonika © 2010 All Rights Reserved P a g e...
  • Page 5: Safety Information

    LST EN 60950-1. The equipment can be used with first (Personal Computer) or second (Notebook) computer safety class, which must be properly grounded. The light or attachable sensors shall comply with all safety requirements listed in LST EN 60950-1 standard. Teltonika © 2010 All Rights Reserved P a g e...
  • Page 6 Do not mount or serve device during a thunderbolt. To avoid mechanical damage of the device it is recommended to transport the device packed in damage-proof pack. Teltonika © 2010 All Rights Reserved P a g e...
  • Page 7 3 mm. Turn off two-pole automatic disconnect device in order to simultaneously disconnect the equipment and all with it associated equipment. Teltonika © 2010 All Rights Reserved P a g e...
  • Page 8: Getting Started

    Internet connection available. It is ideal for remote surveillance and monitoring of temporary or distant sites or mobile assets. Teltonika camera saves installation time and costs as no wired cable installation is required on the clients' premises. The video can be acquired automatically by schedule, on motion detection and/or upon external triggers such as motion sensors or door contacts.
  • Page 9: Attaching Antenna

    The 6-pin terminal block may be used for connecting external alarm sensor or for enabling infrared light source. Most common used sensor examples are given in section “Typical PIR and door sensor connection”. Teltonika © 2010 All Rights Reserved P a g e...
  • Page 10: Camera Access Software And Drivers

    Insert the CD supplied with the camera into CD-ROM drive of your PC. The CD will start up automatically opening installation window. If the window does not appear, run setup.exe file located in the CD. Follow the instructions to install drivers and software for the MVC200. Figure 4. Installation Menu 2.4.2...
  • Page 11: Dvs Client Installation

    DVS Client installation Run the client software DVS_Client_Setup, the window below will pop up. Select components and destination folder, press Install to begin installation. Figure 5. DVS Client installation. Teltonika © 2010 All Rights Reserved 11 | P a g e...
  • Page 12: Network Configuration

    OCX plug-in must be installed for proper camera usage. Click the link at the bottom of Login page and follow onscreen instructions. Remember to close the browser before installation. Figure 7. Link on WEB Login page Teltonika © 2010 All Rights Reserved 12 | P a g e...
  • Page 13: Uninstalling The Drivers And Software

    Note: alternatively driver and software may be removed from Control Panel: Start => Settings => Control Panel => Add or Remove Programs. Select DVS Client (NVX) from the list and then click Remove. Figure 9. DVS Client Uninstall Teltonika © 2010 All Rights Reserved 13 | P a g e...
  • Page 14 Figure 10. NVS ActiveX Uninstall Teltonika © 2010 All Rights Reserved 14 | P a g e...
  • Page 15: Camera Configuration (Web)

    To link camera’s IP address to the static hostname, Dynamic DNS settings must be configured. To configure DDNS connect to the camera Web configuration page, go to the DDNS tab (3.5.3). Teltonika © 2010 All Rights Reserved 15 | P a g e...
  • Page 16: Accessing Web Interface

    Enter User and Password in proper fields and press Login button. The Live Video page should appear. Note: Default login settings are: User – admin Password – admin Figure 11. Login page Teltonika © 2010 All Rights Reserved 16 | P a g e...
  • Page 17: Live Video

    Buffered / Un-Buffered Mode. In Buffered mode video stream is buffered at first and then is displayed. Buffered mode causes a few seconds delay of video stream but the stream is displayed smoothly. Figure 12. Live Video Teltonika © 2010 All Rights Reserved 17 | P a g e...
  • Page 18: Setup

    Adjust device date, time. Click Same with PC to synchronize with PC. Sync With NTP server. Enable time synchronization with NTP time server. NTP server. Set NTP server for time synchronization. Figure 14. Device Date and Time Settings Teltonika © 2010 All Rights Reserved 18 | P a g e...
  • Page 19: User Management

    Internet Protocol for communication between its nodes. Net mask. It is a logically visible, distinctly addressed part of a single Internet Protocol network. Teltonika © 2010 All Rights Reserved 19 | P a g e...
  • Page 20 Password. If GSM operator does not require password, leave it blank. !!! Do not forget to disable PIN code. Otherwise you will not be able to connect to 3G network. Teltonika © 2010 All Rights Reserved 20 | P a g e...
  • Page 21: Ddns

    It is a method of sending Internet Protocol (IP) datagram to a group of interested receivers in a single transmission Teltonika © 2010 All Rights Reserved 21 | P a g e...
  • Page 22: Smtp

    Password. Password of your e-mail account. Sender’s Account. User name or e-mail address of your e-mail account . Receiver’s Account. Any mailbox which can receive e-mails. Figure 23. SMTP Settings Teltonika © 2010 All Rights Reserved 22 | P a g e...
  • Page 23: Video Setup

    3.6.2 OSD (On Screen Display) displays additional information on the image. OSD windows allows you to set channel info, time, text color and position. Figure 25. OSD Settings Teltonika © 2010 All Rights Reserved 23 | P a g e...
  • Page 24: Video Mask

    Hold Ctrl and drag mouse to choose the area. Select color of the mask. Then click OK. Click Clear Mask to delete the Video Mask. Figure 26. Video Mask Teltonika © 2010 All Rights Reserved 24 | P a g e...
  • Page 25: Alarm Setting

    Actions To Take. Notify DVS Client, trigger record, send e-mail. Trigger Alarm Out. Enable to trigger alarm output. Valid Time. Set up time when alarm input is active. Teltonika © 2010 All Rights Reserved 25 | P a g e...
  • Page 26: Alarmout

    Time-length. Set time of recording triggered by alarm in seconds. Allowed range is 20 – 600 seconds. Check Video Channel checkbox to allow recording by schedule. Schedule. Press Add to configure recording schedule (Day, Week, and Month). Teltonika © 2010 All Rights Reserved 26 | P a g e...
  • Page 27: Network Storage

    3. If SD card inserted, it is used as a backup storage when the network temporarily down. When the network is alive again, files on SD card will be transported to server. Teltonika © 2010 All Rights Reserved 27 |...
  • Page 28: Playback

    3.9 Playback Many security applications require recording of video or snapshots that may be reviewed later. MVC200 allows not only sending media content over internet by e-mails but also to record it to SD card. Recorded video may be reviewed in the Playback section. Stored media is grouped by recording date.
  • Page 29: Picture View

    Recorded pictures may be reviewed in the Picture View section. Stored media is grouped by recording date. Set up desired dates in Date Range fields and press Search to see desired pictures. Figure 34. Picture View Teltonika © 2010 All Rights Reserved 29 | P a g e...
  • Page 30: Client Software Instructions Guide

    When logged in for the first time user needs to fill the IP address/domain name in order to trigger the monitor screen. Press icon on the right side of the main window to open Device Management window: Teltonika © 2010 All Rights Reserved 30 | P a g e...
  • Page 31 Refesh. Refresh the camera list. Set IP. Change IP of selected camera. Notes: Camera and pc must be on the same network. Default IP address is 192.168.0.233, gateway is 192.168.0.1. Teltonika © 2010 All Rights Reserved 31 | P a g e...
  • Page 32: Live View

    Press to bring up Video Properties menu where Encoding / OSD / Shelter/ MD parameters can be set. 4.4.1.1 Encoding Encoding tab allows you to set frame mode, stream type, frame rate, I-Frame interval for main and for secondary streams. Teltonika © 2010 All Rights Reserved 32 | P a g e...
  • Page 33 Figure 40. On Screen Display Setup 4.4.1.3 Shelter Shelter tab allows you to mask desired area. Hold Ctrl and drag mouse to choose the area. Click Clear to delete it. Teltonika © 2010 All Rights Reserved 33 | P a g e...
  • Page 34: Device List

    Device List section displays information about connected devices: device name, domain name, channel name, etc. Press to add device. Press for Device Property screen. Press to connect or disconnect the device. Teltonika © 2010 All Rights Reserved 34 | P a g e...
  • Page 35: Interface Structure

    Sound when receive alert info from Device. Select sound file which will sound on alert. Resume connection when disconnection is detected. The camera will retry to reconnect on connection loss. Teltonika © 2010 All Rights Reserved 35 | P a g e...
  • Page 36 Recording Settings. Please refer to Teltonika © 2010 All Rights Reserved 36 | P a g e...
  • Page 37 Press Stay for arrow to add/delete standstill period, press to choose display mode, hold mouse left key and drag wanted channel to the right column or delete it by double clicking the channel name. Teltonika © 2010 All Rights Reserved 37 | P a g e...
  • Page 38 Local User Management tab allows you to add, delete user or modify user settings. Default password is blank. You will be asked for password when returning from full screen. Figure 47. Client Side Local User Management 4.4.4.2.4 Automatic Record Please refer to Teltonika © 2010 All Rights Reserved 38 | P a g e...
  • Page 39 Recording and Playback section for further details. 4.4.4.3 Playback Playback window opened pressing button. Please refer Teltonika © 2010 All Rights Reserved 39 | P a g e...
  • Page 40: Camera Setup

    8001. Restart camera after changing configuration. Changing device name does not require restarting. Figure 49. Device Property Address/Port Note: IP address will be valid only after device restart. Teltonika © 2010 All Rights Reserved 40 | P a g e...
  • Page 41 User can monitor picture by internet from long distance. Choose PPPoE in following dialog then input User Name and Password then press OK. Figure 51. Device Property PPPoE Settings Teltonika © 2010 All Rights Reserved 41 | P a g e...
  • Page 42 Sender’s Account. User name or e-mail address of your e-mail account . Receiver’s Account. Any mailbox which can receive e-mails. Click Send A Test Mail after setup to test your configuration. Figure 53. Device Property E-Mail Settings Teltonika © 2010 All Rights Reserved 42 | P a g e...
  • Page 43 Actions take to response to alarm. Sound alarm, notify client, send e-mail. Output to. Enable to trigger alarm output. Valid period of time. Setup time when alarm input is active. Figure 55. Device Property Alarm In Settings Teltonika © 2010 All Rights Reserved 43 | P a g e...
  • Page 44 Resolution. QCIF (176x144) / CIF (352x288) / Half_D1 (720x288) / D1 (720x576). Figure 57. Device Property Video Channel Settings Note: Settings will be valid only after device restart. Teltonika © 2010 All Rights Reserved 44 | P a g e...
  • Page 45 Current version. Current version of the device. File to upload. Click Open find the file then click Upload. Progress will be show while updating. Do not turn camera off during the update process. Teltonika © 2010 All Rights Reserved 45 | P a g e...
  • Page 46 IP from Device-Side File to review records 4.4.5.13 Miscellaneous UPnP function UPnP (Universal Plug and Play) function allows camera to add TCP and UDP mapping to local router (gateway). Teltonika © 2010 All Rights Reserved 46 | P a g e...
  • Page 47 Figure 61. Device Property Miscellaneous Settings Note: Router must support UPnP function Recommended external port range is 1025-32767. Teltonika © 2010 All Rights Reserved 47 | P a g e...
  • Page 48: Recording And Playback

    Limit of time. Set maximum record length in seconds. When the limit is reached, the following options can be selected: Stop recording. Recording will stop after reaching of the limit. Teltonika © 2010 All Rights Reserved 48 | P a g e...
  • Page 49 4.5.1.2 Automatic-Record Setup Here you can create different schedules for different cameras or groups of cameras. Figure 63. Automatic record setup. New. Create a new schedule. Edit. Edit selected schedule. Teltonika © 2010 All Rights Reserved 49 | P a g e...
  • Page 50: Playback

    Press Add button to open Add Device window. Set IP/Host field to camera’s static IP address or use DDNS domain name. Please see 3.5.3 for details on configuring DDNS. Teltonika © 2010 All Rights Reserved 50 | P a g e...
  • Page 51: Typical Pir And Door Sensor Connection

    The camera allows you to connect various surveillance sensors: door magnet sensor, gas sensor, PIR sensor, smoke sensor, etc. The typical PIR and magnetic door sensor connection example is given in Figure 65. Figure 65. Typical sensor connection Teltonika © 2010 All Rights Reserved 51 | P a g e...
  • Page 52: Troubleshooting

    Routers must be set to enable a PC TCP connecting to the device. Routers use port number to decide which device request is allowed, this function is port transmitting or virtual services. Teltonika © 2010 All Rights Reserved 52 | P a g e...
  • Page 53: Technical Specification

    Note: Before using the equipment, do not unpack it until package temperature reaches operating temperature. It is required if the device was stored in the temperature that exceeds operating temperature range. Teltonika © 2010 All Rights Reserved 53 | P a g e...
