- Page 1 ENCA-CCDN All Weather Color CCD Security Camera With Night Vision NTSC TV System USER MANUAL and SPECIFICATIONS ENCA-CCDN :NPENV2 All Weather CCD Security Camera with Night Vision www.encore-usa.com...
- Page 2 INTRODUCTION: Encore’s ENCA-CCDN All Weather Color CCD Security Camera with Night Vision is a high quality indoor and outdoor camera for your Surveillance security DVR System. Safe to place outdoor on any weather type, it features water and lightning proof. It uses a 1/4“...
- Page 3 Volts DC. Check your surveillance DVR user manual power supply system. Do not focus the camera while in operation to any extreme light, like directly to the sun, laser light, etc. CONNECTION DIAGRAM: ENCA-CCDN :NPENV2 All Weather CCD Security Camera with Night Vision www.encore-usa.com...
- Page 4 DVR, connect the the power input jack to your DVR Setup Box. If you are using Encore’s DVR such as the ENDSS-R4D8 or the ENXDVR-4C you don’t need an extra cabling to power this camera. Otherwise, check your DVR user manual for the camera power supply and connection.
