- Page 1 ® UPER CSE-M34S/CSE-M34T Mobile Rack USER'S GUIDE Rev. 1.0...
- Page 2 UPER CSE-M34S/CSE-M34T User's Guide Table of Contents 1. Packaging List ....................3 2. Technical Specifications ................... 3 3. Jumper Settings ....................4 4. Hardware Installation Procedures ..............6 5. SCSI(Super) GEM Drive Installation Instructions for Windows OS ..8...
-
Page 3: Packing List
The CSE-M34T supports four Serial ATA hot-swappable hard drives that yield a unparalleled storage capacity without compromising productivity by eliminating possible system downtime. The CSE-M34S also accommodates four SCSI SCA 320/160 Hard drives which provide configuration flexibility and maximum data integrity. 1. Packing List... -
Page 4: Jumper Settings
UPER CSE-M34S/CSE-M34T User's Guide 3. Jumper Settings A. Jumper Settings for the CSE-M34S (SCSI): Jumper Description Setting JP14 Delay Start Closed: Enable, Open: Disable (*Default) JP18 Buzzer Reset Closed: Enable, Open: Disable (*Default) JP25 Overheat Temperature Open: 50 1-2: 55... - Page 5 Jumper Settings B. Jumper Settings for the CSE-M34T (SATA): Jumper Description Setting JP18 Buzzer Reset Closed: Enable, Open: Disable (*Default) JP25 Overheat Temperature Open: 45 1-2: 50 C (*Default) 2-3: 55 JP28 Fan Sense 1-2: Enabled (if a fan is not present, the alarm will sound) (*Default), 2-3: Disabled JP26...
- Page 6 UPER CSE-M34S/CSE-M34T User's Guide 4. Hardware Installation Procedures (*Note: For the CSE-M34S: 1. SCSI IDs are assigned automatically by the backplane. Do not set IDs manually on the drives. See the previous section for SCSI ID jumper settings. 2. SCSI termination is enabled by default on the SCSI backplane.)
- Page 7 1. Remove the two screws as shown below: Remove the s c r e w s The CSE-M34T (SATA) Model The CSE-M34S(SCSI) Model 2. Pull out the rear fan bracket as shown below: Pull out the rear fan bracket The CSE-M34S(SCSI) Model The CSE-M34T(SATA) Model 3.
- Page 8 UPER CSE-M34S/CSE-M34T User's Guide 5. SCSI (Super) GEM Driver Installation Instructions for Windows OS Please refer to the following instructions to install the SCSI GEM Driver for the Windows OS systems. (*Note: This driver is not necessary for other Operating Systems. If you have two SCA backplanes, you will need to install the driver twice.)
