Instructions – Parts List
President 10:1 Ratio
Air Spray System
FOR SPRAYING HEAVY FLUIDS FROM 55 GAL. (208
liter) DRUMS
1800 psi (126 bar) Maximum Working Pressure
180 psi (12.6 bar) Maximum Air Input Pressure
Model 225877
Includes Pump, Evenflo Control, Air Supply Hose, Spray Gun, and 100
ft (30 m) Air Atomizing and Fluid Hoses.
Model 225886
Has 25 ft (8 m) hoses,
otherwise same as 225877.
Read warnings and instructions.
See page 2 for table of contents.
306402F
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco 225877
Summary of Contents for Graco 225877
- Page 1 Includes Pump, Evenflo Control, Air Supply Hose, Spray Gun, and 100 ft (30 m) Air Atomizing and Fluid Hoses. Model 225886 Has 25 ft (8 m) hoses, otherwise same as 225877. Read warnings and instructions. See page 2 for table of contents. 306402F...
- Page 2 Warnings ........Installation .
- Page 3 INJECTION HAZARD Spray from the gun, leaks or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. D Fluid injected into the skin is a serious injury.
- Page 4 FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and re- sult in a fire or explosion and serious injury. D Ground the equipment and the object being sprayed. Refer to Grounding on page 5. D If there is any static sparking or you feel an electric shock while using this equipment, stop spray- ing immediately.
-
Page 5: Installation
General Information NOTE: Reference numbers and letters in parentheses in the text refer to the callouts in the figures and the parts drawing. NOTE: Always use Genuine Graco Parts and Acces- sories, available from your Graco distributor. Grounding WARNING FIRE AND EXPLOSION HAZARD Before operating the pump, ground the system as explained below. -
Page 6: Typical Installation
Typical Installation Mount the Evenflo Control (1) to the pump, using the screws supplied with it to attach the mounting plate to the pump base. Remove the screw and lockwasher from the bottom of the control. Position the control over the small hole of the mounting plate and reinstall the lockwasher and screw. -
Page 7: Pressure Relief Procedure
Pressure Relief Procedure With the Evenflo control, its bypass valve, and the pump Relax-A-Valve properly set, fluid pressure is relieved from the pump and hose each time you re- lease the gun trigger. Always engage the gun trigger safety when you stop spraying. To relieve air pressure, close the Evenflo regulators and open the bleed-type master air valve. - Page 8 Fig. 4 Mixing by Circulation (Fig. 4) 1. Close the Evenflo bypass valve (K) by turning the valve handle clockwise. 2. Turn both air regulator handles counterclockwise to the free position. 3. Disconnect the gun air atomizing hose (13*) from the left air regulator.
-
Page 9: Maintenance
WARNING To reduce the risk of serious injury whenever you are instructed to relieve pressure, always follow the Pressure Relief Procedure on page 7. 1. Remove and clean the strainer in the Evenflo body, add light oil to the screen cavity and re- assemble every day. - Page 10 Model 225877 10:1 President Paint Sprayer Includes items 1, 3–15 Model 225886 10:1 President Paint Sprayer Includes items 1, 3, 14–19 Parts 05956...
-
Page 11: Technical Data
40–180 psi (2.8–12 bar) 100 psi (7 bar) 3 gpm (11 liter/min) 10.8 cfm (0.3 m#/min) at 1 gpm (3.8 liter/min) at 70 psi (5 bar) Model 225877 182 lb (83 Kg) Model 225886 95 lb (43 Kg) 20” (506 mm) Qty. -
Page 12: Graco Standard Warranty
Graco Standard Warranty Graco warrants all equipment manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale by an authorized Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
