- Page 1 Vocia ® MS-1 Operation Manual Biamp Systems, 10074 S.W. Arctic Drive, Beaverton, Oregon 97005 U.S.A. (503) 641-7287 www.biamp.com...
-
Page 2: Table Of Contents
table Of cOntentS VOcia MeSSage SerVer 1 (MS-1) featureS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . frOnt panel . -
Page 3: Vocia Message Server 1 (Ms-1) Features
Separate Ethernet ports for IP Control, CobraNet and VoIP • CobraNet audio/control with dynamic use of available bundles over a single Ethernet cable • Rotary switches for unit identification • Rack mountable (1RU) • marked and RoHS compliant • Covered by BIAMP Systems’ warranty... -
Page 4: Front Panel
MS-1 frOnt panel Setup and Use The Vocia software provides an intuitive interface for configuration of the MS-1. The information supplied by this manual relates to physical connections and assignment. For more details on software setup, please consult the Vocia Help File. Power Message Server Network... -
Page 5: Rear Panel
MS-1 rear panel Model MS-1 Device ID BIAMP SYSTEMS LAN1: Control LAN2: Cobranet LAN3: VoIP LAN4: Spare RS232 Port AC Power USB Ports LAN-1 LAN-3 Device ID Entrance (IEC) (control) (VoIP) LAN-2 LAN-4 (CobraNet) (Spare) Device ID The rotary ID switches are located on the back of the MS-1 and give the unit a unique Device ID. The switches are in hexadecimal format. -
Page 6: Ac Power Entrance (Iec)
This plug is the main disconnecting device and should remain readily operable. There are no user interchangeable parts. Please contact Biamp Technical Support or your local distributor for all service requirements. -
Page 7: Installation
MS-1 inStallatiOn Installation The MS-1 requires one 1.75 inch (44.45 mm) high and 19 inch (483mm) wide rack space with 17 inch (432 mm) depth. Mounting the unit using four screws with washers will prevent marring of the front panel. PVC or nylon washers are appropriate. When installing the rack ears, please note that the hardware is not symmetrical. -
Page 8: Specifications & Block Diagram
MS-1 SpecificatiOnS Message Server 1 SPECIFICATIONS Connection: RJ45 with shielded Ethernet/PoE cable Weight: 12 lbs. (5.4 kg) (Cat5, Cat5e, Cat6, or Cat7) Power Consumption ambient Operating (100~240VaC 50/60Hz): < 350 watts temperature Range: 32-113 degrees F (0-45 degrees C) Dimensions: Compliance: EU Directive 2002/95/EC, RoHS directive Height:... -
Page 9: Warranty
9. BIAMP Systems shall not be liable for special, indirect, incidental, or consequential damages, including lost profits or loss of use arising out of the purchase, sale, or use of the products, even if BIAMP Systems was advised of the possibility of such damages. - Page 10 cOMpliance...
