Image Dynamics USA CTX 108 Owner's Manual page 2

* Loudspeaker Enclosure Analysis Program
* LEAP® EnclosureShop 5.2.0.363 May/14/2007
* ©1993-2005 LinearX Systems Inc
* Date: Jul 10, 2008
* Designed by Eric Stevens
* Tested by Matt Borgardt
* Electro Mechanical Parameters
Name= CTX 108
Note= Transducer Model Derivation
Model= TSL
Domain= FreeAir
Shape= Round
Profile= Cone
Fmd= 3.0000 KA
Qmd= 1.0000
Flp= 8.0000 KA
Qlp= 2.0000
Znom= 8.0000
Revc= 7.8000
Sd= 353.0000
Mmd= 120.2540
Pmax= 250.0000
Rtvc= 1.0000
Xgap= 8.0000
Xcoil= 38.1000E3 mm
Xmax= 16.00
Krm= 47.1200E-3 KOhm
Erm= 990.0000E-3
Kxm= 125.6450 mH
Exm= 625.0000E-3
Rms= 6.2006
Mms= 124.0650 g
Cms= 336.2117 uM/N
Vas= 59.8386E-3
Fo= 24.6427
Qms= 3.0980
Qes= 0.5863
Qts= 0.4930
BL= 15.9860
Levc= 4.7300E-3 H
SPLo 83.6740
No= 0.1464
* End of line
CTX 10
Recommended Power Range
80 100
Watts
Specifcations:
Thr 5:18 pm
Ohm
Ohm
cm²
g
W
°C/W
mm
mm
N·S/M
M³
Hz
T·M
dB
%
RMS
L I MI T
175
☯
120 140 160
300
200 250
2 2 2 2 2
400
350
Death
