Teppan yaki grill plate


Table of Contents
Safety instructions for the
This appliance corresponds to the type EN 60
335-2-6 with respect to protection against fire.
Only units of this kind may be fitted one-sided to
adjoining high-level cabinets or walls.
When fitted in combustible material, the NIN 2000,
section 4.2.2 and the fire-protection regulations of
the association of local fire insurance companies
must be observed without fail.
Limit to room width 550 mm, height 127 mm from
lower side of grill plate, depth 560 mm from rear
with a working surface depth of 600 mm. Combus-
tible walls and ceilings must be provided with a
flame-retardant lining above the grill plate in con-
formity with the official fire regulations for the rele-
vant area.
Protection against contact must be ensured by the

Rating plates

Versions with two thermostats

Model Code
TY 58.3 CN
PNC 949 080 711
Model Code
TY 58.3 AL
PNC 949 080 710
Model Code
TY 58.3 SW/SP
PNC 949 080 712

Electrical connection

Electrical connection must be made by a certified
The mains connection to the built-in switchbox
must be made with the existing connecting cable
and corresponding to the connection diagram. An
isolating device with at least 3 mm contact open-
ing to disconnect the appliance from the mains
supply at all poles simultaneously should be pro-
vided in the permanent home installation conform-
ing with NIN 2000.
Warning! While being serviced the appliance
must be disconnected from the power supply. The
rating plate is fitted on the underside of the built-in
Before putting into operation detach any protective
foil from the grill plate.
After connecting to the power supply all grill plates
should be switched on briefly (approx. 2 minutes)
in succession at the 100 °C position to check their
readiness for operation.

Versions with one thermostat

Model Code
TY 38.3 CN
PNC 949 080 708
Model Code
TY 38.3 AL
PNC 949 080 707
Model Code
TY 38.3 SW/SP
PNC 949 080 709
