SIDE BURNER PARTS ASSEMBLY
1.
Install burner into side burner tray lining up
the three cutouts on the underside of the
burner. (See Fig. 22a)
2.
Install burner cap onto burner (See Fig. 22b)
3.
Install grate over burner (See Fig. 23)
LEAK TESTING
Make sure all burners are turned to "OFF".
Turn on the gas at the cylinder (LP models) or main
valve (Natural models). DO NOT turn on the side
burner. Perform a leak test at all connections and
fittings by spraying a 50/50 solution of water and
soap. If any bubbles appear, correct the leak before
attempting to light the grill or side burner.

IGNITOR ASSEMBLY

1.
The Battery, Spring and Ignitor cap must be
installed before using.
2.
Install the battery, positive side first.
3.
Slide spring assembly over battery.
4.
Screw ignitor cap onto ignitor.
Side Burner Assembly
10
Fig. 22a
Fig. 22b
Fig. 23
