Summary of Contents for Shenzhen CBT Electronics Technology AV203
- Page 1 Cassette To USB Converter User’s Manual MODEL: AV203 OPERATING INSTRUCTIONS PLEASE READ THIS OPERATING MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE. ‐ 1 ‐ ...
-
Page 2: Important Safety Instructions
SAFETY INSTRUCTIONS WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash and CAUTION: TO REDUCE THE RISK OF The exclamation point Arrow head within the ELECTRIC SHOCK DO NOT REMOVE Within the triangle is a warning Triangle is a warning COVER (OR BACK) NO USER sign alerting you of Important Sign alerting you of SERVICEABLE PARTS INSIDE. REFER Instructions “dangerous voltage” SERVICING TO QUALIFIED SERVICE Accompanying the product. Inside the product. PERSONNEL IMPORTANT SAFETY INSTRUCTIONS 1. Read instructions ‐ All the safety and operating instructions should be read before the appliance is operated 2. Retain instructions ‐ The safety and operating instructions should be retained for future reference. 3. Heed Warnings ‐ All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow instructions ‐ All operation and use instructions should be followed. 5. Water and Moisture ‐ The appliance should not be used near water; for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like. ... -
Page 3: What's Included
What’s Included? The following items are included with your Cassette2USB Converter: Tape Converter Software CD USB Cable User’s Manual Quick Start Guide 1. Install Software. First, install the professional audio recording software (Audacity) included with your converter. On PC: Insert the software CD into your computer. If installation does not start automatically, browse the CD contents and double‐click the file marked “Setup.” On MAC: Insert the software CD into your computer. Double click on the appropriate “MacSetup” DMG file for your Macintosh. Then, click and drag the “Audacity” icon to your Applications folder to complete the installation. 2. Prepare Your Cassette2USB Converter. Use the included USB cable to plug your converter into your computer. Your computer will install the ... - Page 4 Features 1. Eject Slider: Slide this switch to open the cassette holder. 2. Headphone Jack: You can connect 3.5mm headphones here. 3. USB Port: Use the included USB cable to connect tape recorder to your computer. The USB connection will provide audio from tape recorder to your computer for transferring your recordings to your computer 4. Volume Knob: Adjusts the volume of the audio output. 5. Stop: Press to stop the tape. 6. FF / REW: Press to fast forward or rewind the tape. Note that these buttons will become “reversed” when the tape changes direction. 7. Loop Mode: Selects what the tape does when it reaches the end of a side. When set to the “loop” icon, the tape will automatically switch direction and begin playing the opposite side when one side has finished. When set to the single arrow icon, the tape will simply stop when a side has finished. 8. DIR: Selects the direction of tape playback. This is useful if you want to play the other side of the tape without having to eject it. 9. Play: Press to play the tape. ‐ 4 ‐ ...
-
Page 5: Frequently Asked Questions (Faq)
Frequently Asked Questions (FAQ) 1. What computers is the Cassette2USB Converter compatible with? The software is compatible with Microsoft Windows 7, Vista, XP and Apple Mac OS X. 2. When I record audio from my converter, I don’t get any sound. 1) Check the volume dial on the right side of your cassette converter. Make sure it is turned up to about halfway. 2) Make sure you have the correct recording device set. In the software, click Edit Preferences and set the “Recording Device” to “USB Audio Device”. 3. How do I save my audio recordings as MP3? After recording your audio recording, use the FileExport As MP3 feature inside the software. The first time you do this, you will be asked to locate a file called lame_enc.dll to add this feature to the software. Insert the CD that came with your Cassette2USB Converter and locate this file on the CD. 4. Where do the batteries for the player go? There is a removable slot behind the door on the converter for 2 AA batteries. You’ll need batteries if you want to use the Cassette2USB Converter as a portable tape player. 5. How do I use the Cassette2USB Converter with iTunes? First, convert your cassette tape to WAV or MP3 format and save it on your PC. You can then import your recordings into iTunes and put them on your iPod/iPad/iPhone. 6. My audio recordings don’t sound good. 1) Turn down the volume control on the player; high volumes can cause distorted recordings. 2) Turn down the “Recording” / “Microphone” volume in the software. 3) Under Edit _ Preferences, set “Channels” to “2 (Stereo).” 4) If your recordings still are low quality, it is possible that your original cassette tape’s quality has degraded over time. 7. The software records audio correctly, but I can’t hear anything during playback. 1) First, unplug your Cassette2USB Converter from your PC. Then export your recording as a WAV or MP3 file and exit the software. Finally, play your music in software such as Windows Media Player or iTunes. Note: use earbuds or headphones (plugged into your converter) if you’d like to listen to the music while recording. 2) Make sure you have the correct recording device set. In the software, click Edit _ Preferences and set the “Recording Device” to something like “USB Audio Device”. ... - Page 6 9. Is there a way to make the audio transfer faster? Transfers must be done at normal speed. This is because the Cassette2USB Converter records the actual audio that is emitted by the player. 10. My recording is too fast or too slow. 1) Try loosening your cassette tape’s reel by fast forwarding/rewinding the tape several times. 2) Are you trying to convert a special “long‐play mode” cassette tape? The Cassette2USB Converter supports standard speed cassettes only. 11. My converter does nothing when I press “Play.” 1) You need to either plug your converter into a USB port in your computer, or put batteries in. 2) Try pressing the “DIR” button on the top of the player. If the cassette tape has reached the end of one side, this will play the other side of the cassette tape. 3) It’s also possible that your computer is not providing enough power. Try putting batteries in your converter to power it instead. ‐ 6 ‐ ...
