IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
PR624ES

SNOW THROWER

Always Wear Eye Protection During Operation
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
428508 07.14.09 TH
Printed in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR624ES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Poulan Pro PR624ES

Summary of Contents for Poulan Pro PR624ES

  • Page 1: Snow Thrower

    IMPORTANT MANUAL Do Not Throw Away OWNER'S MANUAL MODEL NUMBER: WARNING: PR624ES Read the Owner's Manual and fol low all Warnings and Safety In struc tions. Fail ure to do so SNOW THROWER can result in serious injury. 428508 07.14.09 TH Always Wear Eye Protection During Operation Printed in the U.S.A.

  • Page 2: Auger Housing / Impeller Assembly

    SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 404928X428 AUGER HOUSING 404931X429 SCRAPER BAR 72270505 CARRIAGE BOLT 5/16−18 X .625 155377 NUT 5/16−18 3 (5x) 4 (5x) 01.07.001-A PART DESCRIPTION 420478...
  • Page 3 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 420493X429 AUGER ASSEMBLY LH 24 420494X429 AUGER ASSEMBLY RH 24 01.07.017-A PART DESCRIPTION 174762X479 SKID PLATE LH 178777X479 SKID PLATE RH 72270506 CARRIAGE BOLT 5/16−18 X .75 751153 NUT 5/16−18...
  • Page 4 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY 2 (EXPLODED) 01.07.026-B NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

  • Page 5: Repair Parts

    SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 175321X479 IMPELLER 427148 GEARBOX ASSEMBLY 188909 BEARING 427146 IMPELLER PULLEY 175322 DISCHARGE BASE 178675X008 CORNER BRACKET 192199 CLEAN OUT TOOL 405400 TOOL CLIP...

  • Page 6: Control Panel / Discharge Chute

    SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE 01.09.010-A PART DESCRIPTION 428272 LEVER/CABLE ROTATOR ASSEMBLY 17501010 SCREW 10-24 X .625 420678 ROTATOR HEAD 405932 ROTATOR PIVOT BRACKET 420675 PULLEY PIVOT 428273 CABLE ASSEMBLY ADJUSTABLE...
  • Page 7 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE PART DESCRIPTION 404770X428 CHUTE WELDMENT 178633X428 DEFLECTOR WELDMENT 420325 DEFLECTOR SEAL 179096X428 STRAP 189713X428 KNOB BLACK 128415 POP RIVET 185600 SHOULDER BOLT 1/4−20 X .704 72270505 CARRIAGE BOLT 5/16−18 X .625...
  • Page 8 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS HANDLES PART DESCRIPTION 419800X479 PLOW HANDLE LH 419801X479 PLOW HANDLE RH 196944 PANEL BRACKET LH 196943 PANEL BRACKET RH 199513 HANDLE GRIP 74780512 SCREW 5/16−18 X .750 74780524 SCREW 5/16−18 X 1.50 751153 NUT 5/16−18...
  • Page 9 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS HANDLES PART DESCRIPTION 419797X479 LOWER TUBE 418313X479 PIVOT SUPPORT 428867 BOLT 5/16-18 X .750 17000616 SCREW 3/8-16 X 1.00 01.05.004-C PART DESCRIPTION 412675X004 INTERLOCK SPRING 414572 INTERLOCK CAM 178831 TORSION SPRING...
  • Page 10 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS HANDLES 01.08.002-F PART DESCRIPTION 412683X479 CONTROL PANEL 424517X479 CONTROL LEVER LH 424516X479 CONTROL LEVER RH 426917X008 TRACTION ROD ARM 426918X008 IMPELLER ROD ARM 412677 INTERLOCK ROD 421613 SPACER 169675 RETAINER 17060410 SCREW 1/4-20 X .62...
  • Page 11 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS HANDLES PART DESCRIPTION 180480 IMPELLER ROD ASSEMBLY 405740 TRACTION ROD ASSEMBLY 180445 SHIFTER ROD TOP 187716 SHIFTER ROD BOTTOM 180447 SPRING SLEEVE 178669 IMPELLER SPRING 180926 TRACTION SPRING 72270505 CARRIAGE BOLT 5/16-18 X .75...
  • Page 12 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS DRIVE 42 EXPLODED 01.02.013-A NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty.
  • Page 13 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS DRIVE PART PART DESCRIPTION DESCRIPTION 198875 SPEED SELECTOR 179831 RUBBER RING ASSEMBLY 175344 BEARING 17501010 SCREW 10-24 X .625 178613 WHEEL HUB 402685X428 END PLATE 74760514 SCREW 5/16-18-.875 17490508 SCREW 5/16-18 X .50...
  • Page 14 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS DRIVE PART DESCRIPTION 188226 (assy of 1a,1b) AXLE ASSEMBLY 179352 AXLE SHAFT 9465M1 ROLL PIN 3/16 01.03.005-B 402691 SPROCKET 174697 THRUST WASHER 179830 BEARING 17490508 BOLT 5/16−18 X .500 155443...

  • Page 15: Chassis / Engine / Pulleys

    SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS CHASSIS / ENGINE / PULLEYS PART DESCRIPTION 423474 COMPLETE LCT ENGINE 418694X428 FRAME 01.00.034-A 150406 BOLT 3/8-16 428867 SCREW 5/16-18 X .750 PART DESCRIPTION 427963X428 ENGINE MOUNTING PLATE 01.01.004-A PART...
  • Page 16 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS CHASSIS / ENGINE / PULLEYS 01.21.003-A PART PART DESCRIPTION DESCRIPTION 408007 IMPELLER BELT 74780520 SCREW 5/16-18 X 1 .00 419744 TRACTION BELT 59289 WASHER 423723X479 IDLER ARM BRACKET 73930500 NUT 5/16-18...
  • Page 17 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS WHEELS PART DESCRIPTION 187831X421 WHEEL ASSEMBLY LH 187866X421 WHEEL ASSEMBLY RH 01.06.001-A NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

  • Page 18: Bag Of Parts

    SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS BAG OF PARTS PART DESCRIPTION 198563 POWER CORD 169675 RETAINER PIN 180684X008 WRENCH 73800600 LOCKNUT 3/8−16 19131316 WASHER 3/8 192090 SHEAR BOLT 1/4−20 X 1−3/4 73800400 LOCKNUT 1/4−20 01.14.004-B PART...
  • Page 19 SNOW THROWER - - MODEL NO. PR624ES (96192002900) REPAIR PARTS DECALS PART DESCRIPTION 181037 DECAL, DANGER 181035 DECAL, DANGER, DEFLECTOR 181042 DECAL, DANGER 181033 DECAL, INSTRUCTION 415391 DECAL, TRACTION LEVER 415390 DECAL, AUGER LEVER 415475 DECAL, SPEED CONTROL 428508 OWNER’S MANUAL, ENGLISH...
