Auto Shut Off - Sanyo CE28FWN6-B Instruction Manual

Switching into /from standby mode
The Standby mode is used for switching the TV set off for short
periods of time. In standby mode the TV is switched off but is still
receiving mains power.
To turn the TV set into standby mode, press the 4 button.
The red power indicator illuminates more brightly.
To turn the TV set ON from standby mode, press any of the follow-
ing buttons: 4, 5, 6 or 0-9 buttons.
If you find the power indicator flashing, please turn the TV
set off with the Mains ON/OFF switch, disconnect the
power cord from the power outlet and contact our Service
desk.
This warning is a sign to let you know that the power
protection function of this TV set is now operating.

Auto shut off

This TV set will automatically switch into the standby mode, 10
utes after a signal is no longer received. The time until the set will
switch off is displayed on the screen.
Use of Audio Output Jacks
This TV provides the audio monitor output jacks on the rear of the
cabinet back. You can connect your audio equipment to these jacks to
give you sound with your audio equipment.
To audio equipment
Selecting of picture size
Screen options
Today there are various transmission formats with different size
ratios, eg. 4:3 , 14:9, 16:9 and video formats such as letterbox.
Auto
It automatically switches to the optimum screen mode according to
the WSS signal provided in the receiving signal source. If the signal
does not have it, the TV keeps current screen mode.
This setting may cause the picture to change when a different
format is received eg. when an advert is received.
WSS (Wide screen signalling)
Some broadcasters transmit this signal and some VCR tapes have it
included . The signal identifies the picture format ratio (16:9, 14:9,
4:3 etc.).
If WSS is not being received and you are not happy with your pic-
ture this TV provides you the option to change it with the following
options.
Press the WIDE button repeatedly to select your desired setting.
Full
4:3 14:9
The whole screen
The whole screen
is filled stretching
is filled stretching
the width.
the height slightly
at the edges.
OPERA
OPERA
AV2 AV1
ANT.75Ω
16:9 Letterbox Video
The whole screen The black bars top
is filled with the and bottom are
corrrect picture present and the
ratio. height is
compressed.
TION
TION
Natural
4:3
Stretches the
picture horizontally
to fill the screen.
The picture is more
stretched at the
edges.
Zoom 14:9
4:3
min-
The correct picture
width is maintained
but the top and
bottom are
cropped.
Title in 14:9
4:3
TITLES ON SCREEN
As zoom (14:9), but
bottom is
compressed even
more to allow
subtitles to be
seen.
Zoom 16:9
4:3
The correct picture
width is maintained
but the top and
bottom are
cropped.
Title in 16:9
4:3
TITLES ON SCREEN
As Zoom (16:9),
but bottom is
compressed even
more to allow
subtitles to be
seen.
Normal
4:3
The correct ratio is
maintained with
black bars on the
left and right.
14:9 16:9
The height is
The picture fills the
expanded to fill the
screen and is
whole screen.
proportionally
correct.
14:9 16:9
Zooms in slightly
Zooms in slightly
cropping the top
cropping the top
and bottom.
and bottom.
14:9 16:9
TITLES ON SCREEN
TITLES ON SCREEN
As zoom (14:9), but As zoom (14:9), but
bottom is bottom is
compressed even compressed even
more to allow more to allow
subtitles to be subtitles to be
seen. seen.
14:9 16:9
Zooms in slightly
Zooms in slightly
cropping the top
cropping the top
and bottom.
and bottom.
14:9 16:9
TITLES ON SCREEN
TITLES ON SCREEN
As Zoom (16:9), As Zoom (16:9),
but bottom is but bottom is
compressed even compressed even
more to allow more to allow
subtitles to be subtitles to be
seen. seen.
14:9 16:9
Black bars left and
Black bars left and
right, picture height
right, picture height
is stretched.
is stretched.
Letterbox Video
The black bars top
and bottom remain
and the height is
compressed to fit
the picture area.
Letterbox Video
The black bars top
and bottom are
smaller and the
picture height is
compressed slightly.
Letterbox Video
TITLES ON SCREEN
As zoom (14:9), but
bottom is
compressed even
more to allow
subtitles to be
seen.
Letterbox Video
The black bars top
and bottom are
smaller and the
picture height is
compressed slightly.
Letterbox Video
TITLES ON SCREEN
As Zoom (16:9),
but bottom is
compressed even
more to allow
subtitles to be
seen.
Letterbox Video
Black bars left,
right, top and
bottom.
7
