ZyXEL Communications P-794H Quick Start Manual

ZyXEL Communications P-794H Quick Start Manual

8 wire g.shdsl cpe with 4 port lan
Hide thumbs Also See for P-794H:

Advertisement

Quick Links

Download this manual See also: User Manual
P-794H
8 wire G.SHDSL CPE with 4 port
LAN
Firmware Version S04.01
Edition 1, 12/2010
DEFAULT LOGIN DETAILS
IP Address:
Username
Password
www.zyxel.com
http://192.168.1.1
admin
1234
Copyright 2010
ZyXEL Communications Corporation

Advertisement

loading
Need help?

Need help?

Do you have a question about the P-794H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZyXEL Communications P-794H

Summary of Contents for ZyXEL Communications P-794H

  • Page 1 P-794H 8 wire G.SHDSL CPE with 4 port Firmware Version S04.01 Edition 1, 12/2010 DEFAULT LOGIN DETAILS IP Address: http://192.168.1.1 Username admin Password 1234 Copyright 2010 ZyXEL Communications Corporation www.zyxel.com...
  • Page 2 Device Panels POWER LED 1-4 ALARM CO LED LED 1-4 RESET SWITCH PORT PORT 1-2 PORT 1-4 GROUNDING TERMINAL AC POWER...

  • Page 3: Hardware Connections

    • WEB BROWSER: Internet Explorer 6.0 and later versions, with JavaScript enabled, or Mozilla Firefox 3 and later versions or Safari 2.0 and later versions. The browser will be used to access the Internet and/or access the P-794H’s Web Configurator. Hardware Connections...
  • Page 4 If you are operating in CO mode, connect the LAN port to a router for Internet access. 4. CID: If you want to configure the P-794H by CLI command, use a console cable to connect the CID port to your computer’s COM port.
  • Page 5 If you do not connect a computer correctly to this port, the LAN light will not turn on. • The CO light is on when the P-794H is operating in CO mode. The CO light is off when the P-794H is operating in CPE mode.

  • Page 6: The Web Configurator

    The Web Configurator The Web Configurator is a web browser tool that allows you to configure the P-794H. The computer and the P-794H need to be in the same IP address range to use this tool. 1. Open your browser and enter http://192.168.1.1 (the P-794H’s default IP address) as the address.

  • Page 7: Internet Access Setup

    Open your web browser and browse to http://www.zyxel.com. You may be prompted to enter your username and password. If the web page opens correctly, your P-794H is ready for you to use. If the web page does not open, you need to enter your Internet access configuration using the Web Configurator - see page 6.
  • Page 8 3. Enter a description for the connection. If your IP address is assigned by your ISP, enter it in the WAN IP addess field. If not, leave it as 0.0.0.0. Type your account username and password. Click Configure. Internet Account 4.

  • Page 9: Point-To-Point Setup

    Point-to-Point Setup You can setup two P-794Hs for fast point-to-point connection by setting one P-794H as the CO and the other P-794H as the CPE and connecting their DSL ports. The two P-794Hs and the computers can be in the same DHCP domain but must have different IP addresses.
  • Page 10 CPE Mode Log into the P-794H you are using as the CPE. Click SHDSL > SHDSL Configuration and select CPE in the Unit ID field. Make sure the other settings on this screen are the same as SHDSL settings of CO. Click Apply.
  • Page 11 Viewing a Product’s Certifications 1. Go to www.zyxel.com. 2. Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3. Select the certification you wish to view from this page. For more information, please refer to the User’s Guide on the provided CD or at the www.zyxel.com download library.
