• Hot! do not touch! the surfaces
of this appliance will be hot during
operation and will retain heat for
a while after shutting off the appli-
ance. severe burns may result.
• carefully supervise children in the
same space as the appliance.
WarninG: iF tHe inForMation in tHis ManuaL
is not FoLLoWed exactLy, a Fire or expLo-
sion May resuLt causinG property daM-
aGe, personaL injury or Loss oF LiFe.
do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any
other appliance.
What to do if you smell gas:
• do not light any appliance.
• do not touch any electrical switches, do not
use any phone in your building.
• immediately call your gas supplier from a
neighbor's phone. Follow your gas suppliers
instructions.
• if your gas supplier cannot be reached, call
the fire department.
installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
Portland
US
a French manual is available upon request. order Form number
875,032cF.
ce manuel d'installation est disponible en francais, simplement
en faire la demande. numéro de la pièce 875,032cF.
WarninGs
otL report no. 6-F-4-5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
care and operation
instructions
OUTDOOR GAS FIREPLACE
ELITE
outdoor Gas FirepLace
p/n 875,032M reV. d 04/2009
MODELS
e36odGne
e36odGne-H
e36odGpe
e36odGpe-H
instaLLer: Leave this manual with the appliance.
consuMer: retain this manual for future reference.
instaLLateur: Laissez cette notice avec l'appareil.
consoMMateur: conservez cette notice pour consula-
tion ultérieure.
aVertisseMent: assurez-Vous de Bien suiVre
Les instructions donnÉes dans cette notice
pour rÉduire au MiniMuM Le risQue d'incendie
d'expLosion ou pour ÉViter tout doMMaGe Ma-
tÉrieL, toute BLessure ou La Mort.
ne pas entreposer ni utiliser d'essence ni d'autre
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
Que Faire si Vous sentez une odeur de Gaz:
• ne pas tenter d'allumer d'appareil.
• ne touchez à aucun interrupteur. ne pas vous servir
des téléphones se trouvant dans le bátiment où
vous vous trouvez.
• appelez immédiatement votre fournisseur de gaz
depuis un voisin. suivez les instructions du fournis-
seur.
• si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incendies.
L'installation et l'entretien doivent être assurés par
un installeur ou un service d'entretien qualifié ou par
le fournisseur de gaz.
SERIES
®
e42odGne
e42odGne-H
e42odGpe
e42odGpe-H
Advertisement
Table of Contents
Related Manuals for Lennox ELITE E36ODGNE
Summary of Contents for Lennox ELITE E36ODGNE
-
Page 1: Care And Operation
ELITE SERIES ® outdoor Gas FirepLace p/n 875,032M reV. d 04/2009 MODELS WarninGs • Hot! do not touch! the surfaces e36odGne e42odGne of this appliance will be hot during e36odGne-H e42odGne-H operation and will retain heat for e36odGpe e42odGpe a while after shutting off the appli-... -
Page 2: Table Of Contents
WarninG: tHese appLiances are not desiGned or intended to Be In selecting this LENNOX Outdoor Gas Appliance you have chosen the finest and most used For cookinG. do not Bar-B- dependable fireplace to be found anywhere. A beautiful, prestigious, alternative to a Que, Heat Food, or roast MarsH- wood burning fireplace. - Page 3 carbon Monoxide poisoning: early signs Tables 1 shows the units' gas orifice size for Minimum inlet gas pressure to these appli- the elevations indicated. ances is 5.0 inches water column (1.24 kPa) of carbon monoxide poisoning are similar for natural gas and 11 inches water column to the flu with headaches, dizziness and/or orifice size (2.74 kPa) for propane for the purpose of input...
-
Page 4: Operation/Care Of Your Appliance
operation and care oF your pressure-tap pilot stage pilot Gas appLiance (inlet) terminal outlet Appliance operation may be controlled by a remotely located wall switch. Ground (tp) Gas controls/control compartment access supply piLot The gas controls can be found beneath the bot- Gas outlet inlet to Burner... -
Page 5: Maintenance Schedule
Maintenance schedule annually (Before the onset of the Burning Season) Maintenance task accomplishing person procedure Inspecting/Cleaning Burner, Logs Qualified Service Technician Inspect valve and ensure it is properly op- and Controls erating. Check piping for leaks. Vacuum the control compartment, fireplace logs and burner area. -
Page 6: Adjustment
Sooting is indicated by black puffs developing at the tips of very long orange flames. Sooting Limit switch detail Limit switch Location results in black deposits forming on the logs, appliance inside surfaces and on exterior sur- faces adjacent to the face opening. Sooting is caused by incomplete combustion in the flames and a lack of combustion air entering the air shutter opening. -
Page 7: Log Placement
Log placement WarninG: LoGs Get Very Hot and rear Log WiLL reMain Hot up to one Hour aFter Gas suppLy is turned oFF. HandLe onLy WHen LoGs are cooL. turn oFF aLL eLectricity to tHe ap- pLiance BeFore you instaLL Grate and LoGs. -
Page 8: Electronic Appliance Checkout
With proper care and maintenance, your appli- ance will provide many years of enjoyment. If you should experience any problem, first refer to the trouble shooting guide in this manual. If problem persists, contact your Lennox distributor. eLectronic outdoor Weather cover... -
Page 9: Wiring Diagrams
We recommend that you record the following important information about your fireplace. Please or Lennox directly: contact your Lennox dealer for any questions or concerns. For the number of your nearest Lennox dealer, please call 1-800-9-LENNOX. Lennox HeartH products... -
Page 10: Lighting Instructions - Electronic
LiGHtinG instructions — eLectronic For your saFety read BeFore LiGHtinG WarninG: iF you do not FoLLoW tHese instructions exactLy, a Fire or expLosion May resuLt causinG property daMaGe, personaL injury or Loss oF LiFe. • Immediately call your gas supplier from a neighbor’s a. - Page 11 instructions d’aLLuMaGe — eLectronic pour Votre sÉcuritÉ, Lisez ces instructions aVant L’aLLuMaGe aVertisseMent: si Vous ne suiVez pas ces instructions à La Lettre, iL pourrait s’en suiVre un incendie ou une expLosion causant des doMMaGes MatÉrieLs, des BLessures corporeLLes ou MêMe des pertes de Vie. a.
-
Page 12: Troubleshooting The Electronic Ignition System
TROuBLEShOOTiNG ThE ELEcTRONic iGNiTiON SySTEM Note: Before troubleshooting, be sure that the appliance main line gas shut-off valve, the gas control valve and the wall switch are in the “ON” position. important: Valve system troubleshooting should only be accomplished by a qualified service technician. syMptoM possiBLe causes correctiVe action... - Page 13 notes: NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
-
Page 14: Replacement Parts List
repLaceMent parts List " 6 " 2 r i F – – – – , y r , y r i r r , y r , y r i r r , y r , y r i r r , y r , y r , y r... - Page 15 repLaceMent parts (riGHt side) (riGHt side) NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
- Page 16 Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. Printed in U.S.A. © 2006 by Lennox Hearth Products p/n 875,032M reV.
