BENDIXKing AV8OR User Manual page 2

SLEEK,
POWERFUL, VERSATILE
Ready to go when you are
The new Bendix/King AV8OR ™ portable Multifunction Display (MFD) takes you to the airport, provides airborne weather and guidance
en route to your destination, and even provides entertainment along the way. Designed by pilots for pilots, the AV8OR's exceptional
graphical user interface means that you'll spend less time entering data and more time piloting.
The AV8OR portable MFD is much more than a simple GPS. It's the perfect traveling companion with built-in music, picture and
movie playing capabilities. It even interfaces with your Bluetooth
the information you want, when you want it – all in an easy-to-use and easy-to-read, affordable package.
In the Air
AV8OR's innovative features push beyond traditional portable
GPS systems.
AV8OR's large 4.3 inch diagonal, high brightness touch screen
sets a new standard for portable systems.
AV8OR's touch-and-see feature lets you identify and get critical
information for objects on the map with a simple tap on the
screen. Obstacle heights, airspace limitations, helipads – they're
all just a touch away.
AV8OR's touch-and-drag feature makes panning the map a
simple, one-touch operation. No more holding a cursor button
and waiting to see what's ahead. Just drag the map to instantly
scan ahead on your course or look to the side for alternate
destinations.
AV8OR's smart profile view lets you plan ahead with a vertical
profile view of terrain, airspaces and obstacles on your course.
Smart profile view Weather view
®
cell phone. Whether for business or pleasure, the AV8OR delivers
A Platform for Situational Awareness
AV8OR's simple connection to your Bendix/King KDR 610 or
WxWorx ™ XM satellite receiver delivers true graphical weather
to your cockpit. A full range of Weather products can be
displayed, including: NEXRAD Composite Reflectivity, Lightning,
METARs, AIRMETs, SIGMETs, Convective-SIGMETs, PIREPs,
TFRs and more.
AV8OR's simple hookup to your Zaon Portable Collision
Avoidance System (PCAS ™ ) XRX ™ provides a variety of traffic
advisory options. Traffic can be shown as an overlay on the
moving map, or displayed on the dedicated Traffic page. As an
added safety feature, traffic alerts can be enabled to 'pop up'
the traffic page regardless of what is presently being displayed.
Knowing what's ahead puts you ahead of the rest. Whether for
business or pleasure, the AV8OR delivers the information you
want, when you want it – all in an easy to use and easy to read,
affordable package.
Traffic view
Pilot Focused and Reliable
A product you can trust, AV8OR's efficient touch screen and exceptional user interface were
derived from the pilot friendly, panel mounted Bendix/King MFD systems. Aviation database
updates as well as flight plan uploads are easily obtained by simply connecting to your PC. Flight
plans created in programs such as FliteStar ™ can be loaded into the AV8OR. Previously flown and
logged flights can be uploaded to a computer and easily displayed in programs such as
Google ™ Earth.
Front View
Scrollable
Data Fields
(User
Configured)
High
Resolution
Terrain
Large 4. 3",
High Bright
Touch
Screen
Status
Window
(GPS, Wx and
Messages)
(Actual Size)
On the Ground
AV8OR's built-in automotive
navigation system provides both
2D and 3D navigation views to
get you where you need to go in
the most efficient way possible.
With more than 10 million Points
of Interest (POI) in the U.S. and
two million POI in Canada, you'll
always be able to find the nearest
shopping, restaurants, gas stations and more. AV8OR's large, 4GB SD Card
means that it comes to you pre-loaded with both aviation and automotive
databases for the entire region of your choosing; with plenty of room to spare.
If that's not enough, AV8OR's built-in speaker provides voice prompts to your
destination, so you won't have to take your eyes off the road. Available driving
regions include U.S./Canada, Europe, Africa, Australia or Mexico/Brazil.
Visit www.BendixKing.com for detailed coverage maps.
Side View
Removable
4GB SD
Card for
Databases
and
Multimedia
Smart
Profile
View
Relax at Your Destination
When you're not flying or driving, sit back,
relax and listen to music, view pictures,
read an electronic book or watch a movie
with AV8OR's built-in media players. The
standard 4GB SD card has room to spare
to add your own media library. AV8OR
also includes ports for video input and
audio output.
