- Page 1 SEDONA Island Assembly Instructions SEDONA Island Assembly Instructions Part #34269 Rev. A...
-
Page 2: Important Safeguards
Important Safeguards: WARNING: Two to three people are needed to set up the island. Failure to do so may result in injury. WARNING: Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other appliance. To reduce the risk of fire, electrical shock or personal injury follow the instruction contained in this guide carefully. -
Page 3: Power Supply
The fully featured premium outdoor kitchen can be created in no time at all. The Mom Friendly, Dad Ready cooking products are designed with the family in mind. Crafted by the Lynx Grill Specialists at our factory in Southern California, each Sedona Grill displays the meticulous fit and finish and high-quality material that have made Lynx products favorites of grilling enthusiasts. -
Page 4: Specifications
PART NUMBER DESCRIPTION PHOTO SPECIFICATIONS TANK RETAINING (14044) WASHER 1/4 X 11/16 2 EA. TRANSFORMER / (14014) BATTERY MOUNTING 8-32 X 3/8 TRUSS SCREWS 2 EA. SIDE BURNER MOUNT- (33839) ING HEX NUT 1/4-20 SS 2 EA SIDE BURNER MOUNT- (32730) ING SCREW 1/4-20 X 1-1/4 PH... -
Page 5: Step 1 Unpacking The Crate
Step 1 Unpacking the Crate Using a manual, or power Philips head screwdriver, remove all the screws from the crate. Then remove the bottom, front and two side panels from the shipping crate. We recommend 2 to 3 people perform setup op- erations. - Page 6 Step 3 Assembling the Rear & Side Panels Assemble the rear panel to the bottom panel by placing the corners of the back panel on top of the bottom panel corners and push them firmly together. Step 3a Step 3b Step 3c Step 3 Continued While one person holds the rear panel in place, attach a side panel to...
- Page 7 Step 3 Assemble the Front Panel With one person holding the rear and side panel in place, assemble the front panel to the bottom by placing the front panel corners on top of the bottom panel corners and pushing them firmly together Tilt the front edge of the side panel away from the bot- tom panel to allow the front panel mounting brackets to pass by threaded mounting screws on the side panel.
- Page 8 Do not plug the extension cord into a power source until you have completed the equipment installation. The island wiring diagram is shown below. If you have any questions please contact LYNX customer care or consult a professional electrician. Strain Relief at all Connections Back Panel Outlet...
- Page 9 Step 5 Mounting the Transformer Locate the 2 transformer mounting screws and the transform- er/battery bracket. Mount the transformer on the rear panel support frame near the rear panel outlet using the pre-drilled Screw Location holes provided. Install the side burner battery bracket below the transformer in the same manner.
- Page 10 Step 7 Install the Countertop With the help of an assistant or two, place the counter top in place jiggle it a little until the walls slip into place, and then secure the top with 2 wing nuts and clamps located under the counter top, at the front and rear.
-
Page 11: Step 10 Making The Connections
Step 10 Making the Connections We recommend a qualified, trained gas service technician perform all pipe fitting procedures and conduct a gas leak test prior to installing the refrigerator. Once installed there will be limited access to the gas piping. Working from the refrigerator cutout, find the stainless steel flexible hose from the side burner. - Page 12 Step 11 Installing the LP Tank The LP Tank retention device can be secured to the door frame with two 1-1/2” long bolts (provided). The LP tank is rested in the retainer and the finger screws are tightened around the base of the tank securing it into po- sition.
- Page 13 See Step 9 Make the electrical connections as shown below, then plug the transformer into the electrical outlet on the rear panel. *Not actual installation, illustration is for demonstration purposes only. TRANSFORMER* hese connectors attach to the battery back up wires on the grill hese connectors attach to the battery back up wires on...
