Gebrauchs- und Montageanleitung
Instructions for installation and use
Instructions de montage et d'emploi
Wichtig:Unbedingt lesen und aufbewahren!
Important:Read these instructions carefully and then store them in a safe place
Important:Lire attentivement et ranger soigneusemnt ce mode d'emploi
Integrierte Kühlschrank
Integrated Refigerator
Réfrigérateur a intégrer
Modell: IKE 166-0
DE
GB
FR
2-14
15-26
27-38
200382809
N/Kü/9. (09.)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kuppersbusch IKE 166-0
Summary of Contents for Kuppersbusch IKE 166-0
- Page 1 Wichtig:Unbedingt lesen und aufbewahren! Important:Read these instructions carefully and then store them in a safe place Important:Lire attentivement et ranger soigneusemnt ce mode d’emploi Integrierte Kühlschrank Integrated Refigerator Réfrigérateur a intégrer Modell: IKE 166-0 2-14 15-26 27-38 200382809 N/Kü/9. (09.)
-
Page 2: Table Of Contents
Instructions for the use of the instructions booklet Notes which are important for your safety or for the proper functioning of the appliance Supplementary information regarding operation and practical applications of the appliance. Tips and notes concerning economical and environmentally sound use of the appliance The symbol on the product or on its packaging indicates that this product may not be treated as household waste. -
Page 3: Safety Instructions
Safety Instructions In the interest of your safety and to ensure the correct Do not damage the refrigerant circuit. use, before installing and first using the appliance, The refrigerant isobutane (R600a) is contained read this user manual carefully, including its hints and within the refrigerant circuit of the appliance, a warnings. -
Page 4: Diposal
Appliance's manufacturers storage Service recommendations should be strictly adhered to. Any electrical work required to do the servicing Refer to relevant instructions. of the appliance should be carried out by a qualified electrician or competent person. Care and cleaning This product must be serviced by an authorized Before maintenance, switch off the appliance and Service Centre, and only genuine spare parts disconnect the mains plug from the mains socket. -
Page 5: Use And Control / Before Use
Use and Control Before Use The temperature inside the appliance is automatically adjusted. Wait 4 hours before connecting the appliance to Setting “1” = hightest temperature, warmest allow the oil to flow back in the compressor. setting Before using the appliance for the first time, wash Setting “6”... -
Page 6: Door Shelves / Hints
Door shelves To help you use your refrigerator correctly, here are some useful hints: To permit storage of food packages of various Raw meat (beef, pork, lamb & poultry): wrap sizes, the central door shelf can be adjusted in in polythene bags and place on top of the salad height. -
Page 7: Cleaning
Melting water flows through defrost water outlet into Clean the inside with warm water and bicarbonate the evaporative tray maintained on the top of of soda. Rinse and dry thoroughly. compressor and evaporates due to warmth of it. To guarantee a safe operation of the fridge, once a Check and clean the outlet of melting year remove the ventilation grill at the base and water coming during defrosting regularly. -
Page 8: Something Not Working
Something not Working Problems may be due to causes which can easily be solved before calling the Technical Service. Please follow these instructions: SOLUTION SYMPTOM Level properly the appliances if it is not well levelled. Door does not close Weight surpasses the storage limit of the door shelf so spread weight more evenly or take some products out. -
Page 9: Customer Service And Spare Parts
Customer service and spare parts If you cannot find the remedy for a malfunction in these operating instructions, please contact your dealer or our customer service department and consult the Guarantee card. Selective ordering of replacement parts can save unnecessary travel and costs. For this reason always provide the following appliance information: Model Name... -
Page 10: Installation
Installation Climate for an ambient classification temperature of Take utmost care when handling your +10 to +32 °C appliance so as not to cause any damages +16 to +32 °C to the cooling unit with consequent possible fluid +16 to +38 °C leakages. -
Page 11: Building-In
Attention! It must be possible to disconnect the appliance from the mains power supply; the plug must therefore be easily accessible after installation. Building-in Dimensions of the recess Height of housing (1) 1225 mm Depth of housing (2) 550 mm 1. - Page 12 6. Place guide (Ha) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied. 4. From the plastic cover (E), which is used to cover the hinge with the pivot pin, you must take away the part as indicated in the drawing.
- Page 13 Open the appliance door and the furniture door at 10. Place the small square on the guide again and 90°. Insert the small square (Hb) into guide (Ha). Put fix it with the screws supplied. together the appliance door and the furniture door Should the alignment of the furniture door be and mark the holes as indicated in the figure.
- Page 14 KÜPPERSBUSCH HAUSGERÄTE AG Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen Telefon: (02 09) 4 01-0, Telefax: (02 09) 4 01-3 03 www.kueppersbusch.de Küppersbusch Ges. m. b. H. Eitnergasse 13, 1231 Wien, Telefon: 01 / 8 66 80-0, Telefax: 01 / 8 66 80 72 www.kueppersbusch.at ·...
