Signalling And Error Correction; Signalling - AEG PROTECT C. 1000 (S) Operating Instructions Manual

6

Signalling and Error Correction

6.1

Signalling

1.
2.
3.
4.
5.
OFF push button (OFF): Press the OFF switch
for about 2 seconds to switch on the UPS
ON push button (ON): Press the ON switch for
about 2 seconds to switch off the UPS.
Deactivate acoustic alarm: By pressing this
switch for about 2 seconds during the alarm an
acoustic alarm can be deactivated.
UPS Test: To execute an UPS self test press this
button for about 2 seconds in the normal operation
mode.
LED Bypass (Bypass): The orange-coloured LED
lights up when the UPS system is supplying voltage
provided by the mains power via the bypass.
LED Inverter (Inverter): The green-coloured LED
lights up if the UPS system is supplying voltage
provided by the mains power via the inverter.
LED Battery (Battery): The orange-coloured LED
lights up when power is supplied by the batteries.
12
11
10
9
8
7
3
6 4
5
2 1
35
