5.2
External Battery Expansions
To achieve longer backup time, it is possible to connect multi-
battery packs. Connect exclusively the following products
together:
PROTECT C. 1000
PROTECT C. 2000
PROTECT C. 3000
PROTECT C. with 1 battery expansion
Fig.: PROTECT C. 1000 and C. 1000BP
1.
2.
with
with
with
Check the correct fit of the UPS and the battery
unit (the casings e.g. have to have the same
dimension).
Now connect both battery connectors using the
supplied
battery
connecting, make sure that you push the plug
quickly and firmly in the battery connectors.
PROTECT C. 1000 BP
PROTECT C. 2030 BP
PROTECT C. 2030 BP
connection
26
cable.
When
