4.3.2

Display

Explanations:
1. OFF-Pushbutton (OFF)
2. ON-Pushbutton (ON) / Alarm off
3. Orange LED bypass (Bypass)
4. Green LED inverter (Inverter)
5. Orange LED for battery (Battery)
6. Green LED for utility power (Line)
7. - 11. Bar graph LEDs (7-10 green / 11 orange) for
7. LED load (0-35%)
8. LED load (36-55%)
9. LED load (56-75%)
10. LED load (76-95%)
11. LED load (96-105%)
12. Red LED fault (Fault)
You will find detailed explanations of the displays on page 35.
UPS battery utilization respectively capacity
(remaining autonomy time)
12
11
10
9
8
7
3
6
4
5
2
battery capacity (96-100%)
battery capacity (76-95%)
battery capacity (51-75%)
battery capacity (26-50%)
battery capacity (0-25%)
22
1
