- Page 1 LMS8-A Mini Switch Installation Guide...
- Page 2 3. Full duplex capability for each port 4. Optional AUI port allows compatibility with other 10 Mbps Ethernet media The LMS8-A has 8 10 Mbps RJ45 ports with an optional AUI interface available on Port 1. Each port is capable of supporting half or full duplex...
-
Page 3: Power Requirements
Note: These tips are additional to the Installation Instructions that can be found on the back of the unit. All ports on the LMS8-A can support full duplex operation - please make sure that each port has the proper switching setting for the desired modes (default switch set- tings are for half duplex). -
Page 4: Cable Requirements
EIA category 3,4 or 5 cables can be supported on the RJ45 connectors. All ports of the LMS8-A are configured as MDI-X ports; Port 2 has an MDI option for connecting to hubs, repeaters or other switches. -
Page 5: Technical Support
6:00 a.m. and 5:30 p.m. (PST) at 800-422-7044 (USA) or 949-453-3990 outside of the United States. Your Lantronix LMS8-A Mini Switch is covered by a five-year limited warranty. WARNING! This device complies with part 15 of the FCC rules. -
Page 6: Declaration Of Conformity
Manufacturer’s Address: 15353 Barranca Parkway Irvine, CA 92618 USA declares, that the product: Product Name: Micro Switch Model Number(s): LMS8-A conforms to the following standards: Safety: EN 60950: 1988 + A1, A2 EMC: EN 55022: 1988 Class A EN 50082-1:... - Page 7 Because it is a store-and-forward device, the LFX2 filters out bad packets from attached network segments, so it can be used as a screen between a problem segment and the network backbone 15353 Barranca Parkway Irvine California 92618 sales@lantronix.com 949-453-3990 Fax: 949-453-3995 1 800-422-7055...
