Table 1
Parts Location
Figure Legend

General Procedure

NOTE: If the Base Module is part of an expanded TL881/TL891 Family MiniLibrary
System, refer to the Compaq StorageWorks TL881/TL890/TL891 Family MiniLibrary
System Maintenance and Service Guide for information on removing the Base Module
from the MiniLibrary system.
To add a second drive to the Base Module:
1. Remove the skin cover, if present.
2. Remove the cover plate.
3. Remove the drive caddy assembly.
4. Install the new drive.
5. Replace the drive caddy assembly.
6. Replace the cover plate.
7. Replace the skin cover.
continued
Description
:
AC power switch
;
Control panel
<
Unlock/Open button and locked
indicator
=
Magazine security lock
>
Leadscrew
Adding a Second Drive 3
