EverFocus EDN3340 Manual

Features

• 1/3" Full HD color CMOS image sensor delivers
high resolution, and supports both H.264 and
M-JPEG in full frame rate
• P-IRIS Lens with a stepper motor for exact
positioning to improves the IRIS performance
• Provides True Day/Night functionality with
automatic IR filter operation
• High Performance Noise Filter improves image
quality
• Extended IR range of up to 20M/ 65.6 ft. with 33
LEDs
• Dual power capability PoE or 12VDC for flexible
installation
• ONVIF / PSIA compliance interoperates with a
broad range of systems
• Built-in micro SDHC slot for a SDHC card enabling
local storage
• Local alarm inputs and outputs
• Two Way Audio transport (line level input/output)

Ordering Information

EDN3340: IP 3 Megapixel Dome
IP Solutions
EDN3340
IP 3 Megapixel Dome Camera
Part Number
Pickup Device
Effective Pixels
Sensitivity

Day/Night

Lens

Video Output

Video Compression

Frame Rate

Image Setting

Interface

Supported Protocols
Power Over Ethernet
Alarm Input : Alarm Output 1 : 1
Audio In/Out
Event Trigger
Notification
Pre/Post Alarm Buffer
SD Card

Power Supply

Power Consumption

Weight

Dimension

Operating Temp
Humidity
Support
Certifications
EDN3340
1/2.8" HD
2048 x 1536
0 Lux @ F1.2 (IR On)
Built-in Auto IR cut filter
Auto Iris, 3-9mm, F1.2-F2.3 P-IRIS
BNC socket, composite 1Vp-p/75ohm For cam-
eras Set-up and test only
H.264/MJPEG
2048 x 1536 @ 15 fps, 1920 x 1080 @ 30 fps
Compression, brightness, sharpness, white
balance, exposure control backlight compensa-
tion, image rotation & mirroring, text and image
overlay
10Base-T/100Base-TX auto-negotiation, RJ-45
socket. Supports MDI/MDI-X auto cross function
TCP/IP, IPV6, UDP, ICMP, DHCP, NTP, DNS,
DDNS,SMTP, SNMP, FTP, HTTP, HTTPs, PPPoE,
UPnP, Bonjour, RTP, RTSP, RTCP, UDP, IGMP,
ICMP, ARP, ONVIF, PSIA
Yes (PoE 802.3af)
Two way audio, 3.5mm mono line input/line out
Compression G.711
Alarm Input, Manual Trigger, Motion Detection
and Schedule Recording
Trigger alarm output, email notification, upload
video to FTP, record video to SD card, record
video to PC and network alarm
5 seconds
Supports micro SDHC for onboard event storage
12VDC & PoE
12VDC 7.44W (IR LEDS on)/ PoE 8.45W (IR LEDS
on)
2.38 lbs
Flush Mount: 4.61" x 4.29" Surface Mount: 5.6"
x 5.23"
-32°F - 104°F
20%-80% non-condensing
ONVIF, PSIA
CE, FCC
