- Page 1 LSW2F8, LSW2F16 10/100 Ethernet Switch Installation Guide...
-
Page 2: Table Of Contents
Table of Contents CHAPTER 1. Introduction 1.1 Product Introduction ....... 2 1.2 Features . -
Page 3: Chapter 1 Introduction
The LSW2F8/LSW2F16 switch can be placed on a tabletop or rack- mounted, and provides the ideal solution for your small, medium, or large Ethernet/Fast Ethernet network. These devices are designed to comply fully with the IEEE 802.3 Ethernet and 802.3u Fast Ethernet... -
Page 4: Features
1.2 Features The LSW2F8 provides two 100BASE-TX ports and eight 10BASE-T ports for Ethernet and Fast Ethernet connectivity The LSW2F8/LSW2F16 comply with the IEEE 802.3 Ethernet and IEEE 802.3u Fast Ethernet standards An Uplink switch on the front panel enables the LSW switch to be... -
Page 5: Product Specifications
Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet Architecture Store and forward switching Connectors LSW2F8 8x10BASE-T/2 100BASE-TX (RJ-45) Fast Ethernet ports LSW2F16 16x10BASE-T/2 100BASE-TX (RJ-45) Fast Ethernet ports Uplink ports Push button to select Uplink or Normal connections: Port 1 and Port 10... -
Page 6: Chapter 2 Using The Lsw Switch
Chapter 2 Using the LSW Switch 2.1 Packing Checklist Your switch product package should contain the following: An LSW2F8 or LSW2F16 10/100 Ethernet Switch One AC Power Cable Four self-adhesive standoffs Rackmount brackets and screws Installation Guide If any of these items are missing, contact your dealer immediately. -
Page 7: Fileserver Link
2.2.1 Fileserver Link The LSW switch can be used to greatly increase the bandwidth between one or more fileservers and the workgroups they serve. Individual 10Mbps workgroup switches can be connected to the ports on the LSW switch, ensuring that traffic in one workgroup will not interfere with the performance of another workgroup. -
Page 8: Backbone Link
Compared to routers, LantronixÕs LSW Ethernet switches are easy to set up and maintain. Several networks can be connected together with a single Ethernet switch, and the forwarding delay is negligible. One or more of the LSW switchÕs 100Mbps links can be used as a high-speed backbone... -
Page 9: 10/100Mbps Bridge
2.2.3 10/100Mbps Bridging The LSW 10/100 Ethernet Switch can allow you to gradually transition between traditional 10Mbps Ethernet and newer 100Mbps Fast Ethernet. The addition of the LSW switch can give immediate increases in performance on the 10Mbps networks, and allows connectivity to be maintained when network stations are transitioned over to 100Mbps Fast Ethernet. - Page 10 Figure 2-4 LSW2F8 Switch Front Panel 10/100 LSW2F8 10/100 Mbps FULL/COL LINK/ACT PORT NO. Figure 2-5 LSW2F16 Switch Front Panel PORT NO. FULL/COL LINK/ACT 10/100 LSW2F16 10/100 Mbps FULL/COL LINK/ACT PORT NO. The LSW 10/100 switches were designed for easy Òplug and playÓ...
-
Page 11: Mounting
2.4 Mounting Your LSW2F8 or LSW2F16 switch is delivered with two brackets for mounting the switch in an EIA standard 19-inch rack. Secure the mounting brackets onto the sides of the LSW switch, fastening them with screws as shown in Figure 2-6. -
Page 12: Connecting The Lsw Switch
2.5 Connecting the LSW Switch Use the following procedures to connect 10BASE-T or 100BASE-TX net- work devices to the LSW switch: LSW2F8 Ports 2-9 Port 1 & Port 10 LSW2F16 Ports 2-18 Normal Uplink PC, Workstation Server Hub, Switch port... -
Page 13: Chapter 3 Led Indicators
Chapter 3 LED Indicators Figure 3-1 shows the LED indicators, which indicate the link status of each of the ports, whether the LSW switch is receiving power, and the presence of network activity and collisions on the network. Figure 3-1 LSW2F16 Front Panel LED Indicators PORT NO. -
Page 14: Full/Col: Full Or Half Duplex/Collision Leds
At this moment, this LED will blink on briefly. 3.4 Link/Activity LEDs Each port on the LSW2F8 and LSW2F16 has a Link/Activity LED which indicates whether a device is detected on the other end. When the port is in Link OK status, this LED also used to indicate activity on the network segment. -
Page 15: Limited Warranty
(www.lantronix.com) or call Lantronix for assistance. Copyright © 1998, Lantronix. All rights reserved. No part of the con- tents of this guide may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. - Page 16 NOTE: The RJ45 ports are not for telephone use. CAUTION: Not for installation in air ducts, plenums or other environmental air handling spaces. Changes or modifications to this device not explicitly approved by Lantronix will void the userÕs authority to operate this device.
-
Page 17: Declaration Of Conformity
(according to ISO/IEC Guide 22 and EN 45014) ManufacturerÕs Name: Lantronix ManufacturerÕs Address: 15353 Barranca Parkway Irvine, CA 92618 USA declares, that the product: Product Name: 10/100 Ethernet Switches Model Number: LSW2F8, LSW2F16 conforms to the following standards: EMC: EN55022(1988)/CISPR 22(1985) Class B EN60555-2(1987) Class A... - Page 18 15353 Barranca Parkway, Irvine, CA 92618 949-453-3990 Fax: 949-453-3995 Sales: 800-422-7055 Support: 800-422-7044 PART NO. 900-140 Rev.A...
