Cisco 6020 Product Overview page 2

Open API. Support for ONVIF 2.0 allows for standards based interoperability and communications with
●
other ONVIF appliances.
Flexible power options: The camera supports Power over Ethernet (PoE) 802.3af, 12 VDC, or 24 VAC
●
power through an optional external power supply.
Medianet support: The camera supports the Cisco Medianet interface. When connected to a Cisco switch
●
that also supports Medianet, the switch recognizes the camera as a video endpoint and then uses
SmartPort macros to set the right network parameters for the video stream on the network. In addition, the
camera can be automatically discovered and configured when connected to Cisco Video Surveillance
Manager 7.0, thereby minimizing installation time and cost.
Features
Table 1 describes the features of the Cisco Video Surveillance 6020 IP Camera.
Table 1.
Item
Imaging device
Image control
Wide dynamic range
Minimum illumination
Lens
Field of view
Camera angle adjustment
Shutter speed
Video compression
Audio compression
Resolution and frame rate
(H.264)
Resolution and frame rate
(MJPEG)
Video streaming
Protocols
Quality of service (QoS)
Power
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information.
Cisco Video Surveillance 6020 IP Camera Features
Specification
1/2.7-in. progressive-scan CMOS
Automatic white balance (AWB), automatic gain control (AGC), automatic exposure shutter (AES), and auto
and manual iris
Approximately 69 dB
● Color: 0.5 lux
● B/W: 0.05 lux
3-9 mm
DC-Iris
Remote focus and zoom
37.5° to 103.7° (horizontal)
21.6° to 71.2° (vertical)
42.6° to 111.21° (diagonal)
Pan: 350°
Tilt: 80°
Rotate: 350°
1/5 to 1/32,000 sec
H.264 and MJPEG
G.711 A-Law, G.711 U-Law, G.726
Refer to Tables 2 and 3
Refer to Tables 2 and 3
● Single-stream H.264 or MJPEG up to 1080p (1920 x 1080) @ 30 fps
● Dual-stream H.264 and MJPEG
Primary stream programmable up to 1280 x 720 @ 30 fps
◦
Secondary stream programmable up to 960 x 544 @15 fps
◦
Dynamic Host Control Protocol (DHCP), Hypertext Transfer Protocol (HTTP), Secure HTTP (HTTPS),
Network Time Protocol (NTP), Real-Time Transport Protocol (RTP), Real-Time Streaming Protocol (RTSP),
Simple Mail Transfer Protocol (SMTP), Secure Sockets Layer/Transport Layer Security (SSL/TLS), TCP/IP,
Cisco Discovery Protocol, Bonjour, Simple Network Management Protocol (SNMP), and Secure Shell (SSH)
Protocol
Differentiated services code point (DSCP) marking and class of service (CoS) marking
12 VDC or 24 VAC through optional external power supply, available separately
PoE (802.3af)
Page 2 of 8
