NETWORK CONTROL FUNCTION

PC control (i.e., remote control) will be possible when this unit is connected to a network.
Camera
1
16
LAN cable
10BASE-T/100BASE-TX
Category 5 Straight

Operations possible with PC control

Menu settings, recording, playback, and remote
operations for PTZ camera are possible from the PC
screen.
Up to a maximum of four PCs can be simultaneously
connected to a single DVR (Digital Video Recorder).
(Example)
Users with user level ID1: 3 PCs
Users with user level ID2 or ID3: 1 PC
Control of the DVR can be switched from the unit to the
PC with MENU settings and vice versa. Note that
operation of the unit will not be affected by simply
connecting a cable.
In order to provide security for computer control, three
types of password are set in accordance with the
different user levels, and this ensures that three
different levels of restrictions can be introduced for
operations. ( P. 39)
DVR (Digital Video Recorder)
Switch
1 2
When this unit is being used while connected to a
network, network settings must be made on the unit
itself. See INSTRUCTION MANUAL "Network settings"
for more details.
TCP/IP settings must be made on the connected PCs
and in accordance with the operating system (OS)
being used on each.
When a pre-existing network is being used, a check
must be carried out by that network's administrator to
confirm that IP addresses do not coincide with other IP
addresses already in use.
Saving and playing back sound
The dedicated application DVR Viewer (Ver. 2.0.0 or
later) must be installed on the system in order to store
or playback audio on a networked PC or to playback
sound-containing video that has been stored on a PC,
CompactFlash card, or the like. ( P. 41)
Please install the software from the CD-ROM included
with this product or download the newest version from
our homepage listed below.
Sanyo website URL:
http://www.sanyosecurity.com
2
CARD CARD
MENU
RESET
EJECT
Switch
3 4

Network settings

PC/AT compatible
machine
English
