Connecting the TelePresence Server
Connecting the TelePresence Server
Before you start
IMPORTANT: Before installing the TelePresence Server, you must read the safety information at
http://www.cisco.com/go/telepresence/safety.
Task 1: Connect power
Connect the power connector on the rear of the unit to the power supply using the supplied power cable.
(There is no On/Off switch.)
Task 2: Connect to Ethernet Port A
Connect an Ethernet cable from Ethernet Port A to an Ethernet switch (rather than a hub, to minimize
interference from other devices on the network). The Ethernet port is a 10/100/1000 Mbps auto-sensing
connection.
Ethernet Ports B, C and D may not be supported in the software supplied with your TelePresence
i
Server. Do not connect to these ports unless the web interface allows you to configure them. Do not
connect multiple ports to the same subnet unless instructed to do so by the web interface.
Cisco TelePresence Server 7010 Installation Guide
Page 6 of 14
