Microsoft ZJA-00001 - Arc Mouse Product Dimensions

Version Information
Product Name
Product Version
Mouse Version
Transceiver Version
Product Dimensions
Mouse Length
Mouse Width
Mouse Depth/Height
Mouse Weight
Transceiver Length
Transceiver Width
Transceiver Depth/Height
Transceiver Weight
Compatibility and Localization
Interface
Operating Systems
Top-line System Requirements
Compatibility Logos
Software Requirements
Tracking Technology
Mouse Tracking System
X-Y Resolution
Tracking Speed
Wireless Technology
Wireless Frequency
Wireless Range
Product Feature Performance
Mouse Button Features
Right & Left Button Life
Side Button Life
Wheel Button Life
Mouse Scrolling Features
Wheel Vertical Scrolling Life
Storage Temperature & Humidity
Operating Temperature & Humidity
Power Requirements
Battery Type and Quantity
Battery Life
Certification Information
Country of Manufacture
ISO 9001 Qualified Manufacturer
ISO 14001 Qualified Manufacturer
Laser Compliance
Restriction on Hazardous Substances
FCC/IC ID
Regulacion para México
Agency and Regulatory Marks
Windows Hardware Certification Kit (WHCK)
Results stated herein are based on internal Microsoft testing. Individual results and performance may vary. Any device images shown are not actual size. This document is provided for informational purposes only and is subject to change
without notice. Microsoft makes no warranty, express or implied, with this document or the information contained herein. Review any public use or publications of any data herein with your local legal counsel.
©2013 Microsoft Corporation. The names of actual companies and products mentioned herein may be trademarks of their respective owners.
Rev. 1308A
® Arc™ Mouse
Microsoft
Microsoft Arc Mouse
Microsoft Arc Mouse
Microsoft 2.4 GHz Transceiver v5.0
4.37 inches (111 millimeters)
2.32 inches (58.8 millimeters)
1.44 inches (36.5 millimeters)
3.10 ounces (88 grams) includes 2 AAA alkaline battery; typical battery weight may vary
1.09 inches (27.6 millimeters)
0.59 inches (15.0 millimeters)
0.27 inches (6.89 millimeters)
0.09 ounces (2.8 grams)
USB 2.0 Compatible
®
• Microsoft Windows
8, Windows RT, Windows 7, and Windows Vista
• Macintosh Mac OS X v10.4-10.7
For Windows-based PC:
Requires a PC that meets the requirements for and has installed one of these operating systems:
• Windows 8, Windows RT, Windows 7, or Windows Vista
• 150 MB Hard Drive
• USB Port
For Macintosh PC:
• Mac OSX v10.4-10.7
• 30 MB Hard Drive
• USB Port
For Windows, Flip 3D requires a PC running Windows Aero
Mac. If you are using Macintosh OS X, the Magnifier enlarges text and images on the entire screen.
• Compatible with Microsoft Windows 8
• Certified for Microsoft Windows Vista
• Mac logo
• Universal Mac logo
• Certified USB logo
No software required
Microsoft-proprietary laser technology
1200 points per inch (47.2 points per millimeter)
Up to 30 inches (762 millimeters) per second
2.4 GHz frequency range
10 feet (3.05 meters) typical. Note: RF range is affected by many factors, such as nearby metallic objects and relative positioning of the mouse and receiver.
4 buttons including scroll wheel button, 1 programmable button
3,000,000 actuations at no more than 4 actuations per second
500,000 actuations at no more than 4 actuations per second
350,000 actuations at no more than 4 actuations per second
Standard horizontal scrolling
100,000 revolutions
-40 °F (-40 °C) to 140 °F (60 °C) at < 5% to 65% relative humidity (non-condensing)
32 °F (0 °C) to 104 °F (40 °C) at <5% to 80% relative humidity (non-condensing)
2 AAA alkaline battery (included)
6 months typical
People's Republic of China (PRC)
Yes
Yes
This device complies with International standard IEC 60825-1:2001-08 for a Class 1 laser product. This device also complies with 21 CFR 1040.10and 1040.11,
except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
This device complies with all applicable worldwide regulations and restrictions including, but not limited to: EU directive 2002/95/EC on the Restriction of the Use
of Certain Hazardous Substances in Electrical and Electronic Equipment and EU Registration Evaluation and Authorization of Chemicals (REACH)
regulation regarding Substances of Very High Concern.
This Class B digital apparatus complies with Part 15 of the U.S. Federal Communications Commission (FCC) rules, Canadian ICES-003, and RSS-210.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Tested to comply with FCC (U.S. Federal Communications Commission) Standards. For home or
office use. The term "IC:" before the certification/registration number only signifies that the Industry Canada technical specifications were met. Model numbers:
1349, Arc Mouse and 1350, 2.4 GHz Transceiver v5.0; FCC IDs: C3K1349 and C3K1350. IC IDs 3048A-1349 and 3048A-1350.
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2)
este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
• CNC Certificate (Argentina)
•
ACA/MED Declaration of Conformity (Australia and New Zealand)
• TRA Certificate (Bahrain)
• ANATEL Certificate (Brazil)
• RSS-210 and IC ID, Certificate of Acceptance (Canada)
• SUBTEL Certificate (Chile)
• CMII Certificate (China)
• EIP Pollution Control Mark, EPUP (China)
•
NTRA Certificate (Egypt)
• WEEE (European Union)
• R&TTE Declaration of Conformity, Safety and EMC (European Union)
• CONATEL Certificate (Honduras)
• ETA Certificate (India)
•
POSTEL Certificate (Indonesia)
• MIC Certificate (Israel)
• TELEC and VCCI Certificates (Japan)
• TRC Certificate (Jordan)
• KC Certificate (Kazakhstan)
•
CCK Certificate (Kenya)
• KCC Certificate (Korea)
•
MPT Certificate (Kuwait)
• MOT Certificate (Lebanon)
• SIRIM Certificate (Malaysia)
•
ICTA Certificate (Mauritius)
ID: 1542631 Microsoft Windows 8
®
®
. If you are using Macintosh OS X v10.3 or higher, the Flip 3D/Instant Viewer button will Expose for
• COFETEL Certificate (Mexico)
•
ANRT Certificate (Morocco)
• NCC Certificate (Nigeria)
• TRA Certificate (Oman)
• PTA Certificate (Pakistan)
• MTA Certificate (Peru)
• NTC Certificate (Philippines)
• ICT Certificate (Qatar)
•
GOST and FAC Certificates (Russia)
• CITC Letter (Kingdom of Saudi Arabia)
• RATEL Certificate (Serbia)
• IDA Approval (Singapore)
• ICASA Certificate (South Africa)
•
BSMI and NCC Certificates (Taiwan)
• NTC SDoC (Thailand)
• CERT Certificate (Tunisia)
• UkrSEPRO Certificate (Ukraine)
• TRA Certificate (United Arab Emirates)
•
FCC ID, Grant of Equipment Authorization (USA)
• UL and cUL Listed Accessory (USA and Canada)
•
URSEC Certificate (Uruguay)
• CONATEL Certificate (Venezuela)
• CB Scheme Certificate (International)
