Wheelock ET70WPA-2475W Installation Instructions

273 Branchport Avenue
Long Branch, NJ 07740
(800) 631-2148
www.cooperwheelock.com
SERIES ET70WP-2475W LOW PROFILE WEATHERPROOF SPEAKER STROBE APPLIANCE
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Series ET70WP-2475W Low Profile Speaker Strobe are for indoor/outdoor use. For outdoor applications the ET70WP-2475W must be wall
mounted to a Weatherproof Backbox (IOB). They are designed for multiple power requirements with high dBA output at each power tap.
This model offers a choice of field selectable taps, 1/8W to 8W for either 25.0VRMS or 70.0VRMS audio systems. The Low Profile design
incorporates a high efficiency speaker for maximum output at minimum power across a frequency range of 400Hz to 4000Hz, and features a
sealed back construction for extra protection and improved audibility. The Low Profile Speaker Strobes can provide a non-synchronized
strobe appliance when connected directly to a Fire Alarm Control Panel (FACP), or provide a synchronized strobe appliance when used in
conjunction with a Sync Module (SM), Dual Sync Module (DSM), or Wheelock's Power Supplies. The Strobes use a Xenon flashtube with
solid state circuitry enclosed in a rugged Lexan® lens to provide maximum visibility and reliability for effective visible signaling.
NOTE: "Lexan" is a registered trademark of General Electric Company.
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: THE ET70WP-2475W APPLIANCE IS A "FIRE ALARM DEVICE - DO NOT PAINT."
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY.
FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION,
INSTALLATION AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT
IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.

SPECIFICATIONS:

Model Color
Lens
ET70WPA-2475W Amber
ET70WPB-2475W Blue
ET70WPG-2475W Green
ET70WPR-2475W Red
NOTES:
1. Strobes will produce 1 flash per second over the "Regulated Voltage" range.
2. All models are for indoor and outdoor use with a temperature range of -31°F to +150°F (-35°C to +66°C) and maximum humidity of
95% RH.
NOTE: THE MAXIMUM WIRE IMPEDENCE BETWEEN STROBES SHALL NOT EXCEED 35 OHMS. THE MAXIMUM
NUMBER OF STROBES ON A SINGLE NOTIFICATION APPLIANCE CIRCUIT SHALL NOT EXCEED 47.
WARNING: THESE APPLIANCES WERE TESTED TO THE OPERATING VOLTAGE LIMITS OF 16-33 VOLTS USING
FILTERED (DC) OR UNFILTERED FULL-WAVE-RECTIFIED (FWR). DO NOT APPLY 80% AND 110% OF THESE VOLTAGE
VALUES FOR SYSTEM OPERATION.
WARNING: CHECK THE MINIMUM AND MAXIMUM OUTPUT OF THE POWER SUPPLY AND STANDBY BATTERY
AND SUBTRACT THE VOLTAGE DROP FROM THE CIRCUIT WIRING RESISTANCE TO DETERMINE THE APPLIED
VOLTAGE TO THE STROBES.
Copyright 2007 Cooper Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
WITH AMBER, BLUE, RED AND GREEN LENS

Table 1: Models and Ratings

Speaker
Voltage Reverberant dBA at 10 Feet
(VRMS) (Rated Watts)
1/8 1/4 1/2
25/70 77 80 83
25/70 77 80 83
25/70 77 80 83
25/70 77 80 83
. All warnings are printed in bold capital letters.
FAILURE TO COMPLY WITH ANY OF THE
Regulated
Voltage
(VDC/VRMS)
1 2 4 8
86 88 91 93
86 88 91 93
86 88 91 93
86 88 91 93
Strobe
Regulated
Voltage Range
(VDC/VRMS)
24 16-33.0
24 16-33.0
24 16-33.0
24 16-33.0
Strobe
Candela
(cd)
25°C -35°C
135 56
54 22
81 33
36 15
P84646 D
Sheet 1 of 5
